03L145715E
OE-Equivalent Replacement Quality
IATF 16949 / ISO 9001 / CE / RoHS
100 pcs
7 - 15 Days
12 Months
| Quantity: | |
|---|---|
R2S K04 10009880065 is handled as the larger Amarok 2.0 BiTDI turbo-core position, but the shared assembly reference makes physical confirmation mandatory.
OE 03L145715E can appear in combined R2S listings and should not be treated as proof of one cartridge side without housing and wheel evidence.
Distributor files must keep K04 and KP35 positions separate even when a buyer submits the same assembly number.
| Specification | Details |
|---|---|
| Product Type | Turbo Core / CHRA Cartridge |
| Fit Turbo Model | R2S K04 |
| Turbo Part Number | 10009880065 |
| OE Reference Number | 03L145715E |
| Engine / Application Reference | Volkswagen Amarok 2.0 BiTDI sequential turbo repair reference |
| Engine Model | CFCA 2.0 BiTDI 163 HP reference |
| Application Reference | Volkswagen Amarok commercial pickup bi-turbo larger-unit reference |
| Reference Year | 2010-2015 reference |
| Supply Direction | Commercial Pickup Bi-Turbo Repair Supply |
| MOQ | 100 pcs |
| Warranty | 12 Months |
| Supplier Brand | Elecdurauto |
| Bi-Turbo Position | K04 larger / low-pressure reference; confirm before order |
| Reference Type | Reference Number |
|---|---|
| Turbo Part Number | 10009880065 |
| OE Reference Number | 03L145715E |
| Assembly Cross Reference | 10009700065 / 10009880102 / 03L145715A / 03L145715G |
| Matching Item | Reference Information |
|---|---|
| Turbo Model | R2S K04 |
| Turbo Part Number | 10009880065 |
| OE Reference Number | 03L145715E |
| Engine Model | CFCA 2.0 BiTDI 163 HP reference |
| Application Reference | Volkswagen Amarok commercial pickup bi-turbo larger-unit reference |
| Turbo Nameplate Photo | Recommended |
| Original Turbo / Cartridge Photo | Recommended when numbers are unclear |
| Larger / Smaller Unit | Larger / low-pressure unit - must be confirmed |
| Special Matching Note | Complete assembly references can appear against both K04 and KP35 service positions |
| Application Reference | Engine | Reference Year | Matching Basis |
|---|---|---|---|
| Volkswagen Amarok commercial pickup bi-turbo larger-unit reference | CFCA 2.0 BiTDI 163 HP reference | 2010-2015 reference | 10009880065 / 03L145715E connect with Amarok 2.0 BiTDI R2S systems; larger-unit identity requires physical confirmation. |
R2S K04 10009880065 supports Amarok repair programs that replace one cartridge while retaining serviceable bi-turbo housings.
Position-controlled stock reduces wrong-side dispatch, installation delays, and disputes between larger and smaller units.
Importers gain a clearer repeat-order record by attaching compressor outlet photos and unit-position notes to each SKU.
Elecdurauto supplies the K04 core for aftermarket replacement after larger-unit confirmation.
R2S K04 10009880065 belongs to a sequential bi-turbo system, so buyers must confirm the exact high-pressure or low-pressure position before ordering. OE 03L145715E, engine code, turbo photos, compressor outlet shape, and cartridge dimensions should be reviewed together. Shared assembly references can appear against both sides of the system, creating a serious wrong-position procurement risk.
Bi-turbo catalogs often list complete R2S assembly references alongside individual K04 or KP35 service parts. As a result, OE 03L145715E may identify the combined system rather than one cartridge position. Distributors should keep the larger / low-pressure unit - must be confirmed record separate and require the removed turbo photo before assigning stock or approving a repeat purchase.
A wrong-side cartridge may have different wheel dimensions, housing interfaces, or flow characteristics even when the assembly reference looks familiar. Installation may become impossible, or the sequential boost system may operate incorrectly. For R2S K04 10009880065, position confirmation protects the workshop from installation delays, return freight, and disputes over a visually similar part.
Yes. A bi-turbo failure can send oil, debris, or abnormal pressure through the shared intake and exhaust system. The workshop should inspect the companion turbo, bypass control, hoses, intercooler, oil lines, and actuator operation before installing R2S K04 10009880065. Replacing only one cartridge without diagnosing the system can lead to another failure.
Combining both positions under one warehouse SKU is not recommended. K04 and KP35 records should show their position, turbo P/N, OE reference, engine calibration, and image evidence separately. Elecdurauto uses position-controlled records for R2S K04 10009880065 so mixed procurement lists can be reviewed without turning an assembly reference into an unsupported cartridge match.
A CHRA replacement is appropriate when the correct position has been confirmed and the related housings, control components, and companion turbo remain serviceable. Buyers should not select a cartridge only because OE 03L145715E appears in a catalog. Proper installation, clean lubrication, correct air routing, and normal operating conditions remain necessary for reliable service.
