Automotive valve service requiring a 24V round lead-wire coil with the same bore, shell and harness layout
Confirm 24v, not stated, lead wire, coil bore and retaining method before installation.
| Quantity: | |
|---|---|
24V Automotive Hydraulic Solenoid Coil is a automotive hydraulic solenoid coil for Automotive valve service requiring a 24V round lead-wire coil with the same bore, shell and harness layout. Buyers should confirm old-coil evidence, 24v, lead wire, coil bore and body construction before approving replacement stock.
Specification |
Confirmed Information |
|---|---|
Product Type |
Automotive Hydraulic Solenoid Coil |
Primary Reference |
Construction-specific replacement |
Cross References |
No verified public OE number assigned |
Voltage |
24V |
Power |
Not stated |
Connector |
Lead wire |
Insulation Class |
F/H |
Application Scope |
Automotive valve service requiring a 24V round lead-wire coil with the same bore, shell and harness layout |
MOQ |
50 pcs |
Delivery Time |
7 to 15 Days |
Warranty |
12 Months |
Complete every control point below before a sample or bulk order is released.
Approval Point |
Buyer Review |
|---|---|
Reference |
Use complete old-coil evidence |
Electrical |
24V; Not stated; verify under load |
Connector |
Lead wire |
Mechanical |
Compare bore, height, body shape and retaining method |
Machine Evidence |
Automotive valve service requiring a 24V round lead-wire coil with the same bore, shell and harness layout |
Separate electrical command, component movement and final machine response so the actual wiring or hydraulic fault is not hidden by parts replacement.
Observed Condition |
Recommended Check |
|---|---|
No magnetic pull |
Check loaded voltage, ground, continuity and coil resistance. |
Intermittent operation |
Inspect terminal retention, lead damage and heat-related winding faults. |
Excessive heating |
Confirm voltage, wattage, duty cycle and free valve-stem movement. |
Connector damage |
Inspect keying, seals, corrosion and harness side loading. |
Correct coil, no hydraulic response |
Inspect the armature, spool, oil cleanliness and machine command. |
When a repeat overheating case is investigated, keep the verified measurements and test result in the service record. Approve the complete old marking, 24v rating, not stated power reference, lead wire, coil bore, body height and retaining method. A matching voltage alone does not prove fit. Send straight-on connector, top-bore and side-profile photographs with measurements so the replacement is selected from electrical and mechanical evidence.
When a connector cavity shows corrosion, keep the verified measurements and test result in the service record. Measure voltage directly across the energized coil while the machine issues the real hydraulic command. An unloaded harness reading can hide resistance at a corroded terminal, relay or ground path. Compare the loaded result with 24v, record polarity where suppression is present and correct the circuit before blaming a new coil for weak magnetic pull.
When a return analysis starts without machine records, keep the verified measurements and test result in the service record. Power affects current draw, heat generation and available magnetic force. A replacement with another wattage may fit the valve stem yet operate too weakly, run hotter or exceed a controller output. Confirm not stated from the old label or approved specification, then compare warm current and temperature during sample testing before releasing a bulk order.
When a warm hydraulic system develops slow response, keep the verified measurements and test result in the service record. Compare pin count, key position, latch direction, cable exit, terminal size and seal arrangement. Similar coil bodies may use a Deutsch, Weatherpack, insert or lead-wire connection that is not electrically or mechanically interchangeable. Photograph the connector face beside a ruler and note any diode or polarity marking before purchasing or adapting the harness.
When cold-start commissioning is completed, keep the verified measurements and test result in the service record. Check terminal retention, harness movement, ground quality and voltage at the coil while the fault occurs. Heat can open a damaged winding, and vibration can interrupt a loose pin or broken lead. If electrical input remains stable, inspect the valve armature for contamination or sticking that changes as oil temperature and viscosity vary.
When a remote service kit is prepared, keep the verified measurements and test result in the service record. Examine the cable exit for cracking, strain, oil ingress and conductor damage near the coil body. Flex the harness gently while monitoring continuity, then inspect the remote connector and terminal seals. Do not pull on the leads during installation, and secure the harness so vibration or sharp edges cannot reproduce an intermittent fault.
When warehouse stock must remain voltage-separated, keep the verified measurements and test result in the service record. Inspect the latch, cavity seals and terminal surfaces before connection. Keep moisture, hydraulic oil and cleaning chemicals away from the contact area, and never force a mismatched plug into the housing. After installation, confirm the connector locks without side loading and that nearby hardware does not press on the coil or cable exit.
Send the complete old marking or component evidence, confirmed voltage, machine information, clear photos, measurements and required quantity for a fitment-focused B2B quotation.
