104975
104975; 1078188; 1104100; XS6H18B647AA; 1006913
Elecdura
IATF 16949, ISO 9001, and other major OEM certification systems
OEM label and ODM customization accepted
100 pcs
7–15 Days
Neutral packaging / private-label review
18 months
104975; 1078188; 1104100; XS6H18B647AA; 1006913
Ford Fiesta Mk IV 1995–2002; Transit Bus/Van/Platform 1991–2000; Ka 1996–2008; Puma 1997–2002; StreetKa 2003–2005; Transit Tourneo 1994–2000
Verify 104975 or a controlled cross-reference, exact Ford model and production period, HVAC equipment, four-pin connector keying, flange outline and mounting holes against the removed resistor.
| Quantity: | |
|---|---|
OE 104975 links several compact-car and commercial-van applications, while 1078188, 1104100, XS6H18B647AA and 1006913 support cross-market searches.
The wide Ford scope is commercially useful only when model and production period stay attached to every line. A distributor should not turn the cross-reference group into a universal Ford claim.
| 104975 Ordering Field | Controlled Requirement |
|---|---|
| Primary OE | 104975 |
| Reference group | 1078188; 1104100; XS6H18B647AA; 1006913 |
| Catalog families | Fiesta; Transit; Ka; Puma; StreetKa |
| Interface evidence | Four-pin connector and mounting flange |
| Approval basis | OE, model, period and removed-part comparison |
Fiesta and Ka volumes may arrive through different channels from Transit and Tourneo service demand. Keep those forecasts visible until the physical samples and source numbers prove one approved unit.
When the vehicle description is incomplete, connector-face and flange photographs are more useful than a broad Ford label. They also create a traceable record for later warehouse or warranty questions.
A golden sample can support repeat supply across approved applications when its OE group, connector face and mounting geometry are documented clearly.
| Approval Stage | Evidence to Retain | Buyer Outcome |
|---|---|---|
| RFQ review | OE, model, year and HVAC configuration | Qualified request |
| Sample inspection | Four pins, flange and resistor layout | Approved identity |
| Program grouping | Passenger and van samples compared | Controlled consolidation |
| Incoming check | Carton OE and sampled geometry | Release decision |
| Field review | Speed symptom, motor current and connector condition | Useful claim evidence |
Loss of selected fan speeds can point toward the resistor, but a tight blower motor or overheated terminal can damage the replacement. Inspect the surrounding circuit before treating the module as the only fault.
For repeat complaints, record current draw, connector discoloration and airflow condition. Those facts help distinguish electrical overload from an incorrect or defective resistor.
Use the catalog-listed Fiesta Mk IV, Transit variants, Ka, Puma, StreetKa and Transit Tourneo periods. Keep the exact model and year with the inquiry because the OE group spans different vehicle programs.
They are controlled cross-references for OE 104975. Approval still requires the source number and a matching connector, flange and resistor layout.
Only after samples from both demand streams match the approved 104975 unit. Preserve separate forecast lines even if production is later consolidated.
Photograph the four-pin face straight on, the keying, mounting holes and the resistor element. Include a scale or dimensions when no readable OE remains.
It is a common resistor-circuit symptom, not an identity proof. Check the switch, harness, blower motor current and OE before ordering.
Ford applications within the broad model group can use adjacent control designs. HVAC equipment narrows the candidate before physical comparison.
Check terminal tension, heat damage and blower current, and repair the harness as required. Installing a new resistor into a damaged plug can cause another failure.
Use the primary OE and approved reference group, then retain customer-specific model wording where required. Avoid a generic Ford resistor label without an OE.
Send OE, model, year, HVAC details, connector photographs, annual quantity, destination, packaging, labeling and sample requirements.
Send Elecdura the source OE, Ford application mix and clear interface photographs for your 104975 program. We can compare the evidence before passenger and van quantities are combined.
For recurring orders, define golden-sample retention, label hierarchy and incoming inspection frequency so each approved application remains traceable.
