12V: 3935458 / SA-4763-12; 24V: 3935459 / SA-4763-24
OE-Equivalent Replacement Quality
IATF 16949 / ISO 9001 / CE / RoHS
50 pcs
7 - 15 Days
12 Months
| Quantity: | |
|---|---|
SA-4763 uses 3935458 for 12V and 3935459 for 24V across Cummins 5.9L and 8.3L service demand. The family sits beside SA-4762 in many catalogs, so the complete label and physical geometry must remain visible throughout purchasing.
Item | Confirmed Information |
Product Type | Fuel shutdown solenoid |
OE / Reference Numbers | 12V: 3935458 / SA-4763-12; 24V: 3935459 / SA-4763-24 |
Electrical Version | 12V or 24V, selected by the SA-4763 OE group |
Application Scope | Cummins 5.9L and 8.3L engine applications using the confirmed SA-4763 configuration |
MOQ | 50 pcs |
Delivery Time | 7 - 15 Days |
Warranty | 12 Months |
Select 3935458/SA-4763-12 for 12V or 3935459/SA-4763-24 for 24V. Then compare the connector face, bracket angle, hole spacing and rod end against the removed unit rather than relying on the shared engine description.
Matching Point | Buyer Action |
3935458 | 12V SA-4763-12 group. |
3935459 | 24V SA-4763-24 group. |
Family identity | Retain SA-4763; do not shorten the inquiry to a generic Cummins solenoid. |
Mounting | Measure hole centers and bracket position. |
Output | Confirm rod-end style, free length and required travel. |
Low voltage, a corroded connector or excessive linkage preload can reduce stroke even when the coil clicks. Check voltage at the connector during actuation and verify that the rod can move the pump lever without binding.
Service or Order Situation | Recommended Review |
Audible click, short stroke | Measure voltage under load and inspect mechanical preload. |
Intermittent hold | Check connector tension, relay contacts and ground. |
Rod reaches stop, engine continues | Inspect fuel-lever adjustment and pump-side movement. |
Bracket twists | Verify the correct SA family and mounting-hole pattern. |
State the complete SA-4763 voltage group, Cummins engine, connector, bracket dimensions, rod geometry and order quantity.
RFQ Item | What to Provide |
OE / reference | 12V: 3935458 / SA-4763-12; 24V: 3935459 / SA-4763-24 |
Voltage | 12V or 24V, selected by the SA-4763 OE group |
Application | Cummins 5.9L and 8.3L engine applications using the confirmed SA-4763 configuration |
Photos | Old label, connector face, mounting bracket, rod or cable end and one complete removed-part view |
Commercial request | Quantity, destination market and packing requirement |
Yes. 3935458 and SA-4763-12 form the confirmed 12V group for Cummins 5.9L and 8.3L service. The old label and machine voltage should agree before physical matching begins.
3935459 and SA-4763-24 identify the verified 24V group. Keep 3935459 separate from 3935458 on RFQs, packing lists and stock locations to avoid a mixed-voltage shipment.
Both families appear with similar Cummins engines, which encourages broad cross-referencing. The SA suffix identifies a specific configuration, so the bracket, rod and connector must match before any substitution is approved.
The coil may be receiving some power while voltage drop, weak ground, internal wear or linkage resistance limits force. Measure voltage at the loaded connector and disconnect the linkage for a controlled mechanical inspection.
No. Harness colors can change across equipment and previous repairs. Use the service schematic and terminal function to identify pull, hold and ground, then confirm the connector body matches the removed unit.
Send the full OE and voltage, Cummins engine and serial, old label, connector face, bracket-hole centers, rod-end dimensions, failure symptom and quantity. Mixed 12V and 24V requirements should be listed separately.
Send the verified SA-4763 group, voltage, Cummins application, mounting evidence and quantity for quotation.
