Product Description
As a professional heavy-duty brushless cooling fan manufacturer and export wholesale supplier, Elecdurauto focuses on providing 27V industrial cooling solutions for overseas distributors, generator parts traders, truck parts wholesalers, and industrial equipment importers who require stable quality, controlled cost, and long-term supply.
Unlike light-duty or retail cooling fans, this series is developed for:
Long-hour continuous running without interruption
High ambient temperature and poor ventilation conditions
Dusty, humid, rainy, and coastal environments
Unstable power supply in many developing markets
In real export business, our customers are mainly located in Africa, the Middle East, South America, and Southeast Asia, where equipment reliability directly determines business reputation and repeat orders. This model is built exactly for those markets.
This Elecdurauto heavy-duty brushless cooling fan is widely used in truck cooling systems, diesel generator sets, construction machinery electrical compartments, and industrial automation cabinets. It is a functional industrial matching fan, not a VIN-locked OE replacement part.
Heavy-Duty Long-Haul Truck Cooling
Continuous Generator Room Ventilation
Electrical Cabinet Thermal Management
Extreme-Duty Machinery Cooling Solutions
The WL233001 cooling fan is engineered for heavy-duty trucks, diesel generator sets, and industrial machinery that require high airflow and long-hour operation under harsh working conditions.
| Item | Specification |
|---|---|
| Voltage Range | 16–32VDC |
| Test Voltage | 27V |
| Static Pressure | 0Pa |
| Load Current | ≤5A |
| Speed | 2300 rpm |
| Max Air Volume | ≥2100 m³/h |
| Rated Power | 140W |
| Blade Diameter | 330mm (13 inch) |
| Connector Type | / |
| Control System | / |
| Protection Level | IP68 |
| These specifications make the WL233001 suitable for high-temperature, dusty, and humid environments found in trucks, generator rooms, and industrial equipment enclosures. |
The WL233001 is a universal industrial cooling fan designed for trucks, diesel generator sets, construction machinery, and commercial power equipment.
It is not VIN-locked and fits a wide range of heavy-duty applications for global aftermarket distributors.
| Equipment Category | Reference Brands |
|---|---|
| Heavy-Duty Trucks | Volvo, Scania, Mercedes-Benz, MAN, Isuzu |
| Construction Machinery | Caterpillar, Komatsu |
| Generator Sets | Cummins, Perkins |
| Industrial Power Equipment | Various OEM brands |
Unlike traditional brushed fans that suffer from carbon brush wear and frequent mechanical degradation, Elecdurauto brushless cooling fans eliminate brush friction entirely. This allows the fan to operate continuously for extended periods without performance decay.
The Elecdurauto brushless motor operates with optimized electromagnetic control, delivering higher electrical efficiency with lower internal energy loss. Compared with brushed motors, less power is wasted as heat.
In heavy-duty applications, unstable torque leads to:
Speed fluctuation
Airflow inconsistency
Unstable cooling performance
Elecdurauto's brushless motor ensures steady torque output across the full speed range, even under long-hour continuous operation and fluctuating voltage environments.
Brushed motors fail mainly due to:
Brush wear
Sparking
Carbon dust accumulation
Overheating after long-term use
Elecdurauto brushless motors eliminate these inherent weaknesses, significantly lowering overall failure rates in real export markets.
Elecdurauto heavy-duty cooling fans are widely supplied to global distributors, generator manufacturers, industrial equipment assemblers, and project integrators, serving long-term bulk purchasing and engineering applications across different markets.
Heavy-Duty Cooling Fan Assemblies
Durable Blower and Motor Units
OE-Grade Cooling Fan Solutions
Professional Fan Clutch Range
Elecdurauto focuses on small and medium bulk export wholesale, which perfectly fits the purchasing behavior of overseas distributors and local import traders.
✅ Trial order: 30 pcs
✅ Standard wholesale: 50–100 pcs
✅ Long-term cooperation: 100+ pcs per shipment
This 27V 330mm brushless cooling fan delivers powerful and stable airflow to quickly remove internal heat from trucks, generators and industrial equipment. It effectively prevents overheating shutdown, component aging and thermal failure, ensuring electrical systems can operate continuously and safely under heavy load.
With IP68 waterproof & dustproof protection, a fully sealed motor chamber and automotive-grade waterproof connectors, this fan continues to operate reliably in:
Heavy rain regions
Dusty mining and desert construction sites
Coastal high-humidity areas
Muddy and vibration-intensive off-road environments
By combining fast heat dissipation with extreme environmental protection, this cooling fan is engineered not only for technical performance, but also for long-term wholesale business stability.
Monthly production capacity: 5,000–10,000 pcs
Stable motor and blade raw material supply
Dedicated export assembly inspection line
Priority scheduling for 30–100 pcs wholesale orders
Elecdurauto provides flexible OEM services for overseas distributors, including:
Voltage customization
Connector type customization
Fan speed curve tuning
Brand logo printing
Color box & packaging design
OEM helps distributors:
Build brand identity
Avoid pure price competition
Improve local market control
18-month international warranty
Technical response within 24 hours
Quality issue replacement for bulk orders
Long-term spare parts and technical support
All Elecdurauto heavy-duty brushless cooling fans are manufactured under a strict quality management system and comply with international safety and performance standards required for global export markets.
The WL233001 is designed for heavy-duty applications such as long-haul trucks, Cummins/Perkins diesel generator sets, construction machinery, industrial electrical cabinets, and power equipment cooling compartments. It is not VIN-locked and fits universal industrial systems, making it ideal for export markets in Africa, the Middle East, South America, and Southeast Asia.
Yes. The WL233001 is built with an IP68 protection level, allowing it to operate reliably in dusty, humid, rainy, or coastal regions. Many customers in tropical countries choose this model due to strong environmental tolerance and stable airflow performance.
The fan supports 16–32VDC, making it stable even in locations with unstable voltage or fluctuating generator output—common in Africa, Southeast Asia, and South America. This wide range protects equipment from shutdown or overheating caused by power inconsistency.
The fan delivers ≥2100 m³/h high-volume airflow with a 330mm blade diameter. This makes it suitable for generator enclosures, heavy trucks, and industrial machinery that require rapid heat dissipation and long-hour continuous cooling.
Yes, WL233001 uses a high-efficiency brushless motor.
Key benefits include:
Longer service life
Lower noise and vibration
Reduced power consumption
Stable operation during long continuous running
Lower maintenance cost for fleet operators and generator owners
This fan is a universal heavy-duty industrial cooling fan, not an OE-specific or VIN-locked part.
It can be installed in aftermarket applications or integrated into generator sets, machinery, and cooling cabinets. If you need installation guidance, mounting dimensions, or compatibility checks, we can provide engineering support.
The WL233001 uses a standard open-end design and supports various customization needs.
Control type: direct control (no PWM) for this model.
If your project requires AMP, Deutsch, or sealed connectors, we can customize based on MOQ.
We provide an 18-month warranty for all export customers.
The warranty covers manufacturing defects, motor issues, and functional failures under normal industrial usage. This helps importers, truck part wholesalers, and generator service companies reduce after-sales risk.
MOQ is typically 50–100 pcs, depending on packaging and customization requirements.
Lead time:
7–15 days for regular stock
20–30 days for large orders or OEM customization
We also support consolidated container shipping for multi-SKU orders.
Yes. We offer sample support for project evaluation, distributor testing, or generator retrofit trials.
Samples can be shipped within 3–7 days, and we help customers in Africa, the Middle East, and Latin America with fast courier options.
