DCP99504 10PA15C A2 130 mm 12V Heavy-Duty A/C Compressor for John Deere

DCP99504 A/C Compressor Wholesale Positioning for John Deere Distributors

DCP99504 gives purchasing teams a stronger starting point than a model-family request alone. The number is associated with John Deere agricultural equipment, while the catalog narrows the offered assembly to 10PA15C, 12V and a two-groove 130 mm clutch. That combination is what Elecdura quotes as the complete replacement unit.

An importer consolidating several John Deere references should retain DCP99504 as the line identity through enquiry, proforma invoice, sample inspection and repeat order. Removing the number after quotation makes it easier for a visually similar 10PA15C compressor to be substituted later.

DCP99504 A/C Compressor Configuration for Purchasing Managers

The DCP99504 purchasing definition combines John Deere use, 10PA15C, R134a, 12V, direct mounting and a 130 mm pulley. Keeping these facts on one approval sheet helps buyers compare offers without reducing the decision to the part number alone.

If a competing quotation shows a different outer clutch measurement, hold it as a separate configuration. The approved DCP99504 line uses 130 mm, and that dimension should follow the product from sample approval through warehouse receiving.

DCP99504 A/C Compressor Cross-Reference Control for Importers

Number matching comes first, but it is not the only check. A buyer should compare the A2 belt profile, pulley diameter, 12V connector, mounting width, manifold face and hose clearance before describing the compressor as a direct replacement for the machine in question.

For first-article approval, photograph the DCP99504 label area and every mechanical interface. The purchasing file should make it possible for a different inspector, months later, to decide whether a repeat shipment matches the approved sample without relying on memory.

DCP99504 A/C Compressor First-Article Checks for B2B Buyers

Inbound inspection should reconcile the carton mark, compressor reference, clutch geometry and connector before the unit enters saleable stock. The team should also look for open ports, damaged caps, bent terminals, impact marks or a rotated head that changes hose routing.

DCP99504 stock should not share an unlabeled location with generic John Deere 10PA15C products. A separate bin record carrying 130 mm, A2 and 12V reduces cross-picking when a distributor handles both combine and tractor compressor programs.

DCP99504 A/C Compressor Stock Segregation for Agricultural Wholesalers

Customers may enquire with AZ44541 or a John Deere machine description, including the 2266 family. Those details help route the request, but they do not prove that every machine uses the same head, mount and pulley configuration shown here.

When a customer supplies only AZ44541 or a vehicle list, request the removed compressor photographs and measurements. Cross numbers should be treated as routing clues until the 10PA15C, A2 130 mm, voltage and physical interfaces have been reconciled.

DCP99504 A/C Compressor Quotation Inputs for Procurement Teams

A distributor RFQ should include DCP99504, machine model, readable original references, clutch details, requested quantity, delivery country and packaging expectations. If the buyer manages mixed fleets, a separate line should be created for each confirmed compressor layout.

Elecdura can review neutral cartons, private-label artwork, sample quantities and recurring supply after identity approval. The quotation will state the controlled DCP99504 build so quality inspection and replenishment teams use the same commercial definition.

DCP99504 Heavy-Duty A/C Compressor Buyer FAQ

The following purchasing questions address the configuration, evidence and commercial controls most likely to affect a DCP99504 wholesale order.

What defines this DCP99504 A/C Compressor for a buyer?

Use 10PA15C, 12V, A2 130 mm, R134a, the John Deere application and the exact approved product images together; no single attribute is sufficient.

Can a similar 10PA15C A/C Compressor replace DCP99504 automatically?

No. For DCP99504, a shared compressor family does not establish the same clutch, voltage, mount, head, ports, connector or hose direction for the intended John Deere machine.

Which pulley data controls the DCP99504 A/C Compressor?

The offered DCP99504 configuration uses A2 and 130 mm. For DCP99504, both the belt profile and measured diameter should be checked against the removed complete assembly.

What electrical detail matters on the DCP99504 A/C Compressor?

This DCP99504 configuration uses 12V. DCP99504 approval requires the machine system, connector shape, terminal arrangement and visible coil position to be confirmed.

What should be included in a DCP99504 A/C Compressor RFQ?

A DCP99504 RFQ should provide the machine model and serial information when available, original references, label and interface images, quantity, destination, delivery target and packaging request.

How should wholesalers receive the DCP99504 A/C Compressor?

Compare the delivered unit with the approved image set, then inspect the A2 130 mm clutch, 12V connection, mounting ears, head, ports, caps and carton identity.

Can Elecdura support private-label supply for the DCP99504 A/C Compressor?

Yes. Neutral packaging, private-label presentation and batch inspection can be discussed after the exact DCP99504 sample and purchase specification are accepted.

Does this DCP99504 A/C Compressor page replace service procedures?

No. For DCP99504, qualified workshops must follow the relevant machine and A/C system procedure for refrigerant recovery, flushing, oil balance, evacuation, charging and installation.

Request a DCP99504 Heavy-Duty A/C Compressor Wholesale Quote

Send the John Deere application, removed-compressor references and images, requested volume, destination and packaging needs. Elecdura will review the 10PA15C 12V A2 130 mm complete A/C compressor configuration before issuing a quotation.
