Two 24V, 12-tooth aftermarket starter configurations for MAN D2066 Euro 4 applications: 2710C at 5.5kW and 2800 MAN at 8kW. Compare the separate specifications, product photos and drawings below, then specify the configuration required for your order.
51262017199、M9T61971
| Quantity: | |
|---|---|
Two 24V, 12-tooth aftermarket starter configurations for MAN D2066 Euro 4 applications: 2710C at 5.5kW and 2800 MAN at 8kW. Compare the separate specifications, product photos and drawings below, then specify the configuration required for your order.
24V
12 teeth
44 mm pinion
MAN D2066 Euro 4
The two configurations share the replacement references, voltage and tooth count, but have different power ratings. Select by the required installation and configuration code; an 8kW rating alone does not establish interchangeability with the 5.5kW unit.
Request a quotation| Specification | 2710C · 5.5kW | 2800 MAN · 8kW |
|---|---|---|
| Configuration code | 2710C | 2800 MAN |
| Rated power | 5.5kW | 8kW |
| System voltage | 24V | 24V |
| Pinion teeth | 12 | 12 |
| Pinion outside diameter | 44 mm | 44 mm |
| Mounting register diameter | Ø92 mm | Ø92 mm |
| Mounting holes | 3 | 3 |
| MAN replacement reference | 51262017199 | 51262017199 |
| Mitsubishi replacement reference | M9T61971 | M9T61971 |
| Wood Auto cross-reference | STR71119 | STR71119 |
For MAN D2066 Euro 4, 10.5-litre, six-cylinder inline diesel-engine applications using references 51262017199 or M9T61971.
Match the engine application and replacement reference to the required 2710C or 2800 MAN configuration. Check the corresponding mounting drawing and electrical connections before ordering.
| Vehicle / engine brand | MAN |
|---|---|
| Engine | D2066 |
| Emissions generation | Euro 4 |
| Displacement / layout | 10.5 litres / inline six cylinders |
2710C drive-end view
2710C rear connections
Compare the mounting register, flange-hole pattern and drive-end position for the configuration you are ordering. The side and rear views also show the motor envelope and electrical connection positions.
Installation-check concept · AI-assisted visualization
| Reference brand | Part number | Relationship |
|---|---|---|
| MAN | 51262017199 | Replacement reference |
| Mitsubishi | M9T61971 | Replacement reference |
| Wood Auto | STR71119 | Cross-reference |
Specify 2710C, 5.5kW or 2800 MAN, 8kW when requesting a quotation. Elecdura supplies aftermarket replacements; the reference brands identify the replacement application.
No. A higher power rating does not confirm mounting fit, wiring compatibility or suitability for a particular vehicle. Compare the required configuration with its drawing and the installed starter before changing versions.
No. Engine designation alone does not identify every starter installation. The replacement number and the electrical and mounting configuration must also match the vehicle being serviced.
Send the quantity required for 2710C 5.5kW and/or 2800 MAN 8kW, destination country or port, and any packaging or label requirements. Include the installed starter number and engine details for the application you are sourcing.
Email your enquiry
