123708124 Ursus Zetor 10T Starter Motor Wholesale

123708124 Starter Motor Wholesale Fitment for Ursus and Zetor tractor applications using the listed 10T configuration

Agricultural-equipment distributors, tractor rebuilders and starter wholesalers use 123708124 to keep Ursus and Zetor tractor applications using the listed 10T configuration demand tied to one 12V, 2.8kW, 10T CW configuration. The practical distinction is the 12V 2.8kW 10T module-3.175 catalog configuration, which should be checked before a similar heavy-duty housing is accepted.

A useful enquiry pairs 123708124 with the equipment record, old-starter label and clear front, side and terminal images. Add the order quantity, destination and required date so technical selection, sample planning, carton marking and freight options can be addressed in one response.

123708124 Starter Motor Mounting Dimensions for Distributor Approval

123708124 Ursus and Zetor tractor applications using the listed 10T configuration 12V 2.8kW 10T starter mounting dimensions.

Use the 123708124 technical drawing to check locating-pilot profile from the drawing, drive-end projection from the drawing and mounting-face pattern from the drawing. Add the mounting-hole layout from the drawing to the receiving sheet. These are practical controls for an approved sample because they can be measured before the starter is installed or released to branch stock.

Complete the 123708124 comparison with 12V, 2.8kW, the 10T drive, module 3.175 and CW rotation. Review pinion condition, terminal location and available cable clearance together. These controls prevent a valid OE search result from being treated as automatic physical interchangeability.

123708124 Starter Motor Reference Group for Wholesale Sourcing

1. Search group: 123708124, 19798, 9142722, 443115144722 can help distributor teams locate the relevant starter family.

2. Order boundary: Confirm the complete reference with 12V, 2.8kW, 10T, CW, the drawing and terminal photographs before accepting one physical unit.

123708124 Starter Motor Distributor Stock and Delivery Support

MOQ begins at 20 pieces, with normal lead time of 7–15 days after order confirmation and an 18-month warranty under agreed terms. For 123708124, the offer can distinguish samples, available stock and production quantities while confirming carton protection and the shipment plan for the destination.

Use the 10T drive and complete tractor record to distinguish this unit from adjacent Jubana variants. Once that boundary is fixed, purchasing can separate urgent units from routine replenishment and define branch quantities, stock labels and freight timing without encouraging an unverified substitute.

The production video gives importers and fleet buyers a view of Elecdura starter assembly and electrical checks. For 123708124, use it alongside the product-specific reference, application and physical controls on this page, rather than treating a general factory presentation as evidence of fitment.

123708124 Starter Motor Questions from Commercial Buyers

How should a buyer request samples and bulk pricing for 123708124 in an Ursus Zetor 10T fleet sourcing program?

Provide the full reference and application, not only a broad brand name. Attach front, side and terminal views of the removed starter and state quantity, destination, required date and packaging needs. For 123708124, Elecdura will respond with the matching specification, MOQ, availability, commercial terms and freight choices.

Which details separate 123708124 from similar starters used around Ursus and Zetor tractor applications using the listed 10T configuration during fleet sourcing?

For 123708124, ask the workshop for the removed starter label and the exact equipment record. Match 12V, 2.8kW, 10T and CW, then compare the locating diameter, mounting holes and terminals. If one of those items changes, request another quotation instead of accepting the similar housing.

Can a purchasing team consolidate every 123708124 reference into one stock line in an Ursus Zetor 10T fleet sourcing program?

The references identify a related sourcing family, not automatic interchangeability. Use 123708124, 19798, 9142722, 443115144722 to locate possible matches, then confirm 12V, 2.8kW, 10T, CW and the mounting face. Any difference in drive position, terminal layout or locating diameter requires a separate product decision.

What pre-installation circuit review supports replacement with 123708124 during an Ursus Zetor 10T fleet electrical check?

Record battery voltage at rest and during the start attempt, then test both main cables under load. Check grounds, terminal tightness and the control feed to the solenoid. Supplying those readings with an enquiry for 123708124 helps the workshop avoid replacing a sound starter when the actual fault is elsewhere.

What should be measured on the drive end before releasing 123708124 to stock during an Ursus Zetor 10T fleet inspection?

For 123708124, check mounting-hole layout from the drawing, locating-pilot profile from the drawing and drive-end projection from the drawing. Record the 10T pinion, rotation and terminal position so the warehouse can isolate a mixed or incorrectly labelled unit before dispatch.

What should an importer include in the replenishment forecast for 123708124 in an Ursus Zetor 10T fleet program?

Build the forecast around actual equipment counts, failure history and the time needed to replenish each service location. For 123708124, keep the specified pinion and mounting interface visible in the stock record. This reduces emergency substitutions and gives purchasing a clearer basis for MOQ, packing and delivery discussions.

What should a warehouse inspect when 123708124 starter motors arrive during an Ursus Zetor 10T fleet receiving check?

For 123708124, match carton and product labels to the purchase order, then sample 12V, 10T, mounting-hole layout from the drawing and terminal protection. Check the flange and pinion for shipping damage. Record lot numbers and arrival photographs, and isolate any different configuration before it is placed in saleable stock.

What traceability details should accompany a warranty enquiry for 123708124 in an Ursus Zetor 10T fleet review?

Keep the carton or product traceability code and note when and where 123708124 was installed. A review should include symptoms, operating time, old and replacement-unit photographs, cable and battery readings and any ring-gear observations. Complete records allow technical support to respond without repeated requests for basic information.

123708124 Ask for Starter Motor Export Pricing

Email info@elecdurauto.com with 123708124, the supported Ursus and Zetor tractor applications using the listed 10T configuration record, old-unit photographs, quantity, destination and required arrival date. Elecdura will use those details to confirm the 12V, 2.8kW, 10T CW starter and prepare wholesale pricing with MOQ, lead time, packing and freight.
