129908-77010 Komatsu 4D95S 12V 2.5kW 9T Starter Motor Wholesale

129908-77010 Komatsu 4D95S 2.5kW Starter Motor Wholesale

Engine rebuilders and equipment dealers may encounter several references from the same Hitachi family. Treating 129908-77010 as a 2.5kW product with its own drive position gives sales and purchasing teams a usable distinction when serving Komatsu 4D95S and Yanmar 4TNE94 customers.

Check 12V, 2.5kW, 9T, module 3 and clockwise rotation as one set, then compare the centered two-hole face. The Ø13.5 holes, Ø95 locating diameter and short 18/21 mm drive references are critical when another related starter shares the engine family but not the same output or nose.

129908-77010 12V 9T Starter Specifications and Compact Dimensions

A complete warehouse line should read 129908-77010, 4D95S or 4TNE94, 12V 2.5kW, 9T and clockwise rotation. This prevents the product from being collapsed into a general S13 replacement and keeps the required 2.5kW configuration visible through quotation and receiving.

129908-77010 Komatsu 4D95S Starter Dimensions for Buyers — compare the drawing with the removed starter before placing a volume order.

Ask for a centered front photograph that shows both Ø13.5 mounting holes and the Ø120 face. Compare the Ø95 locating diameter, 18 mm pinion-side reference and 21 mm nose-to-face dimension, as these compact measurements provide a fast physical separator for this version.

129908-77010 Reference Matching for Komatsu and Yanmar Buyers

129908-77010 appears beside 129900-77010, S13-204, S13-205 and S13-404 in parts searches. Use those numbers to find the family, but carry the 2.5kW rating and measured drive end on every offer so customers receive the intended configuration.

Equipment dealers can assign this version to confirmed 4D95S or 4TNE94 customers and keep other family variants on separate shelf labels. That discipline supports faster counter decisions, clearer returns analysis and more accurate forecasts when multiple workshops draw from the same regional warehouse.

129908-77010 Starter Motor Supply for Industrial Equipment Stock

Before distributing the first shipment, sample the 2.5kW labels, nine-tooth pinions, compact drive position, mounting ears and solenoid connections. Cartons should show 129908-77010 and the rating clearly so branch staff do not mix it with neighboring S13-family stock.

The Elecdura production video provides a practical view of starter assembly and electrical testing for import programs. Industrial-equipment buyers can use it while setting inspection points, marking requirements and delivery schedules for 129908-77010 replenishment.

129908-77010 Komatsu 4D95S Starter Motor FAQs for B2B Buyers

What distinguishes the 129908-77010 2.5kW version from related starters?

Keep the complete 129908-77010 number with 12V, 2.5kW, nine teeth, module 3 and clockwise rotation. Then compare the Ø95 locating diameter and short 18/21 mm drive references. These features give equipment dealers a separate physical and electrical identity even when other S13-family starters share the Komatsu 4D95S or Yanmar 4TNE94 application.

Why is a centered front photograph important for 129908-77010?

The two mounting holes and locating face can look similar when photographed at an angle. A centered image shows both Ø13.5 holes, the Ø120 face and Ø95 locating diameter without perspective distortion. Pair it with a side view of the 18 mm and 21 mm positions, allowing purchasing to compare the compact drive end before accepting a volume quotation.

How should 129908-77010 be separated from other S13-family warehouse stock?

Use a shelf line that includes the lead number, 2.5kW rating, 9T drive and confirmed 4D95S or 4TNE94 customer group. Place related but different-output versions under separate labels and retain the accepted mounting photographs. This makes counter picking clearer, simplifies returns analysis and prevents a similar motor body from becoming the only basis for branch transfer.

What should an engine rebuilder send when requesting 129908-77010?

Provide the engine model and build details, complete removed-starter numbers, clear 2.5kW label, straight front and side photographs, terminal arrangement, quantity and required date. Mention whether the starter will support a rebuilt engine, workshop stock or equipment already awaiting repair. This information lets the supplier address the compact two-hole configuration and appropriate delivery timing.

Which dimensions should be verified on the first 129908-77010 sample?

Check both Ø13.5 mounting holes, the Ø120 face, Ø95 locating diameter, 18 mm pinion-side reference and 21 mm nose-to-face position. Confirm nine teeth and the cable side at the same time. Recording these measurements with the accepted sample gives incoming inspection a practical comparison for later units without depending only on the printed reference number.

Can 129900-77010 be listed beside 129908-77010 on an enquiry?

It may be listed as a related search number, but the offer should keep 129908-77010 as the lead identity and state 2.5kW plus the compact 18/21 mm drive position. Include the old-unit photographs and engine details. This prevents purchasing from assuming that every reference in the family represents the same output and mounting geometry.

What fault information helps when a workshop requests 129908-77010?

Describe whether the old starter clicks, cranks slowly, spins without engagement or remains silent. Add battery voltage, loaded cable-drop results, ground condition and ring-gear observations where available. The service context helps distinguish an electrical-system issue from a failed starter while the supplier confirms the 2.5kW nine-tooth unit, reducing the chance of a repeated complaint after installation.

What commercial details are needed for a 129908-77010 volume order?

Send the confirmed engine or machine information, complete old-unit identity, 2.5kW label, mounting photographs, quantity by warehouse, packing preference, destination and delivery schedule. State whether the order is a first sample, urgent repair batch or regular replenishment. Elecdura can then prepare suitable price breaks, inspection points, carton marking and shipment options for this exact version.

Request 129908-77010 Komatsu Starter Motor B2B Pricing

Send the Komatsu machine or Yanmar engine model, complete 129908-77010 marking, 2.5kW label, straight mounting-face, pinion and terminal photographs, quantity, destination and required date to info@elecdurauto.com. Elecdura will compare the compact drive configuration and return B2B pricing and lead time.
