128000-7600 Volvo TD60 9T Starter Motor Distributor

128000-7600 Volvo TD60 9T Starter Motor Value for Fleet Distributors

The 9T version serves Volvo TD60-family demand where a shared 128000-7600 reference can otherwise point buyers toward the more common 11T option. A separate product identity lets legacy fleet specialists quote, label and replenish this tooth-specific requirement clearly.

The two-ear flange, Ø89 locating face and 24V rating are not enough to distinguish this unit from the 11T variant. Count nine pinion teeth on the removed starter, check module 3 and retain a close drive photograph before confirming supply.

128000-7600 9T Starter Motor Drawing for Wholesale Comparison

This version combines 24V, 4.5kW, 9T, module 3 and clockwise rotation. The 9T designation must stay visible throughout the quotation and receiving process because the base reference and mounting housing overlap the separately listed 11T starter.

128000-7600 9T Starter Motor Dimensions for Volvo TD60 Orders — compare the drawing with the removed starter before placing a volume order.

Its housing drawing uses two Ø11 mounting holes, an Ø127 reference circle, Ø89 locating diameter and 48 mm and 18 mm axial positions. These measurements establish the shared Volvo face, while the photographed nine-tooth pinion establishes the actual variant.

128000-7600 Starter Motor Variant Checks for Volvo Parts Importers

The 128000-7600 to 128000-7604 group and references LRS02153, 420760, 8113860 and 8192262 can assist product search. They should always be paired with 9T, the TD60-family engine and old-unit views on the purchasing request.

A distributor supporting older Volvo fleets can isolate 9T demand in a dedicated bin and customer history. That separation prevents urgent workshop orders from drawing on 11T stock simply because the reference number and mounting face appear to agree.

128000-7600 9T Starter Motor Legacy Supply and Factory Video

On arrival, count the teeth on more than one unit and inspect the shared flange, locating face, terminal protection and 9T labels. Photographs of the sampled pinions provide a practical reference before the shipment is divided among branches.

The video below presents Elecdura starter-motor assembly and electrical testing for B2B supply. Legacy Volvo specialists can consider that capability together with 9T identification, smaller-volume planning, export protection, lot labels and delivery schedule.

128000-7600 Starter Motor FAQs for B2B Buyers

What is the first check for the 9T 128000-7600 variant?

Confirm that the removed starter has nine pinion teeth and photograph the full gear from the end. State 9T on the enquiry, carton label and purchase order together with the Volvo engine code. Elecdura will then compare module 3, clockwise rotation and the two-ear dimensions, keeping the 9T version distinct from the related 11T product.

Why is 128000-7600 alone insufficient for the 9T order?

The reference group also appears on an 11T product with similar housing geometry. A buyer must therefore add the actual tooth count, engine application and old-unit images. Elecdura uses the full combination rather than the shared OE alone, helping purchasing avoid a version mix that might only become visible during installation or ring-gear engagement.

How should the 9T pinion and drive position be verified?

Count nine teeth, confirm module 3 and clockwise rotation, then compare the side view with the 48 mm and 18 mm axial references. The photograph should show the pinion at rest and the flange face in one plane. This lets Elecdura review the gear and position together instead of accepting a tooth count without its mounting context.

Which application data should accompany the 9T Volvo request?

Provide the exact TD60B, TD60C, TD61G or TD63E engine code, host truck or equipment model, and chassis or serial details when available. Add the old-starter reference and photographs. This information helps Elecdura judge whether the stated 9T variant belongs to the customer's installation and gives distributors a useful description for future supply.

Should the first 9T order use a confirmed reference unit?

A reference unit is useful when it is tied to the identified Volvo engine and clearly shows the nine-tooth pinion, two-ear flange and terminals. Compare those features before volume supply, then retain the accepted image set for receiving. The reference unit supports consistency but should not be applied automatically to another engine or an 11T request.

What warehouse practices reduce 9T and 11T picking errors?

Use separate item codes and bin locations, print 9T prominently on the label, and attach a clear pinion image to the product entry. Require the picker or checker to confirm the version before dispatch. When both variants ship in one order, use distinct carton marks and keep each quantity separated on the packing list.

How should mixed 9T and 11T Volvo quantities be packed?

Pack each variant in separately marked cartons with 9T or 11T visible beside the OE, then group the cartons by version on the pallet. The packing list should show separate line quantities and carton ranges. Protect the pinions and terminals in the same way, but do not use identical outer labels that force receiving staff to open every box.

What will Elecdura state in the 9T distributor offer?

Elecdura will identify the 9T module-3 128000-7600 variant and the reviewed Volvo application before listing quantity-based pricing, lead time, packing choices and delivery terms. Any remaining pinion or old-unit question will be stated clearly. The buyer can then issue a purchase order that remains separate from the 11T version throughout supply.

Request 128000-7600 Volvo 9T Starter Motor Distributor Terms

Send the Volvo engine or vehicle details, complete old-unit reference, close pinion and terminal photographs, required quantity, packing needs and destination to info@elecdurauto.com. Elecdura will review the 128000-7600 9T variant and return distributor terms.
