128000-8170 Lister Petter LPA3 Starter Motor Wholesale

128000-8170 Lister Petter Starter Motor Identification for Wholesale Buyers

128000-8170 is intended for Lister Petter LPA3 and related LPW-series industrial engines, including selected Caterpillar-powered equipment records. For industrial-engine distributors, generator-service suppliers and compact-equipment rebuilders, the commercial value is a clearly bounded replacement that can move from inquiry to sample and repeat order without losing the engine, OE or physical version that was originally approved.

Lister Petter engine families are frequently ordered by a short LP designation, which can conceal the starter power, tooth count and flange change needed for a correct replacement. Generator-service buyers should also retain the engine build number and the removed starter's broad triangular face because the machine enclosure can limit cable and solenoid clearance even when the electrical rating appears suitable. Link the full LPA3 or LPW engine record to the Denso group, then compare eleven teeth, two M10 points, the Ø126 mm mounting reference, Ø89 mm drive end and 27 mm offset. That record gives purchasing, sales and arrival-control staff one traceable definition when the same demand reaches them under different service numbers.

128000-8170 Starter Motor Specifications and Mounting Data for B2B Sourcing

Use the technical image to compare the approved mounting and drive-end controls before a sample or commercial batch is released.

Link the full LPA3 or LPW engine record to the Denso group, then compare eleven teeth, two M10 points, the Ø126 mm mounting reference, Ø89 mm drive end and 27 mm offset. The image is a fitment reference and should be checked against the workshop-supplied old starter or released comparison unit rather than scaled from the screen.

128000-8170 Starter Motor OE Boundaries for Distributor Stock

The usable interchange group starts with 128000-8170, 128000-8171, 228000-5790, 228000-5791, 428000-4020. Those references are valuable for locating stock, but the release remains conditional on the LPA3 / LPW3 / LPW4 or machine record and the physical controls shown above.

Lister Petter engine families are frequently ordered by a short LP designation, which can conceal the starter power, tooth count and flange change needed for a correct replacement. Generator-service buyers should also retain the engine build number and the removed starter's broad triangular face because the machine enclosure can limit cable and solenoid clearance even when the electrical rating appears suitable. Before consolidating customer numbers into one SKU, link the full LPA3 or LPW engine record to the Denso group, then compare eleven teeth, two M10 points, the Ø126 mm mounting reference, Ø89 mm drive end and 27 mm offset.

• Fitment boundary: Lister Petter LPA3 and related LPW-series industrial engines, including selected Caterpillar-powered equipment records.

• Interchange focus: Lister Petter engine families are frequently ordered by a short LP designation, which can conceal the starter power, tooth count and flange change needed for a correct replacement. Generator-service buyers should also retain the engine build number and the removed starter's broad triangular face because the machine enclosure can limit cable and solenoid clearance even when the electrical rating appears suitable. Link the full LPA3 or LPW engine record to the Denso group, then compare eleven teeth, two M10 points, the Ø126 mm mounting reference, Ø89 mm drive end and 27 mm offset.

• Buyer record: industrial-engine distributors, generator-service suppliers and compact-equipment rebuilders should retain 128000-8170, 128000-8171, 228000-5790, 228000-5791, 428000-4020 with the accepted physical comparison and customer requirement.

For Lister Petter LPA3 / LPW3 / LPW4 sourcing, the retained geometry combines 2 × M10 mounting positions, Ø126 mm mounting reference, Ø89 mm drive-end reference and 27 mm axial reference. Additional service identifiers include LRS01539, LRS1539, 18988N, STR70329. A quotation for this line should arrive with engine model and build number, complete Denso or Lucas reference, equipment type, old-unit dimensions and electrical-terminal photographs; that information lets industrial-engine distributors, generator-service suppliers and compact-equipment rebuilders distinguish this configuration before stock is committed.

128000-8170 Starter Motor Sampling, Packing and Wholesale Supply

Check the Lister Petter engine label, 11T pinion and broad triangular face; retain one measured sample for generator and industrial-engine repeat orders. Record the sample result against the ERP product identity and customer account before the lot becomes available to sales.

Standard wholesale MOQ begins at 20 pieces. Neutral packing is available, and qualified private-label programs can be reviewed after the product label, barcode, carton strength and protective inserts have been approved for this exact reference.

The video below shows Elecdura starter-motor production and electrical testing. It demonstrates supply capability; the product purchased under this page remains the 128000-8170 configuration defined by the OE, application and physical checks above.

128000-8170 Starter Motor FAQ for B2B Procurement

For LPA3 / LPW3 / LPW4, which machine record should accompany 128000-8170?

In the LPA3 / LPW3 / LPW4 128000-8170 identity file, use the application record for Lister Petter LPA3 and related LPW-series industrial engines, including selected Caterpillar-powered equipment records, including the engine designation LPA3 / LPW3 / LPW4 and serial or production information when available. For this Lister Petter number set, add the full old-starter number and photographs. Within the 128000-8170 sourcing record, this allows the vendor to separate a machine-family description from the actual starter version and gives the reseller a repeatable reference after the first master unit is accepted. For the Lister Petter LPA3 / LPW3 / LPW4 item, the usable identity chain is 128000-8170, 128000-8171, 228000-5790, 228000-5791.

For LPA3 / LPW3 / LPW4, why can the OE group not be approved by number matching alone?

For the LPA3 / LPW3 / LPW4 fitment, references such as 128000-8170, 128000-8171, 228000-5790, 228000-5791 guide the search, but they do not show every physical revision or a wrongly labeled original starter. In this Lister Petter application, cross-check 12V, 2.0kW, 11T and CW, then use the mounting and connection checks. For the defined 128000-8170 scope, lister Petter engine families are frequently ordered by a short LP designation, which can conceal the starter power, tooth count and flange change needed for a correct replacement. For the LPA3 / LPW3 / LPW4 fitment, generator-service purchasers should also retain the engine build number and the removed starter's broad triangular face because the machine enclosure can limit cable and solenoid clearance even when the electrical rating appears suitable. In this Lister Petter application, a controlled cross-reference is a conclusion from those checks, not the only input. For LPA3 / LPW3 / LPW4, the version boundary is 11T, 2.0kW, Ø126 mm mounting reference and the complete OE group.

For LPA3 / LPW3 / LPW4, what should be photographed on the removed Lister Petter starter?

At the 11T drive check, take a square image of the drive end, a side view showing nose depth and solenoid clocking, a clear label photograph, and a rear view of the battery and switch connections. For the 128000-8170 pinion review, include a ruler when the OE is unreadable. Within the LPA3 / LPW3 / LPW4 drive record, these views support the physical release described for this product without forcing sales staff to guess from one angled photo. The Lister Petter release uses 11T with CW rotation, so both details belong on the sample and carton checks.

For LPA3 / LPW3 / LPW4, how is the 2.0kW version kept separate in stock?

During mounting review for 128000-8170, put 2.0kW, 11T and the primary 128000-8170 reference on the internal label and receiving checklist. At the LPA3 / LPW3 / LPW4 flange check, do not rely on the outer casting color or a broad application name. For the Lister Petter installation comparison, when a vendor or customer proposes a supersession, compare a physical master unit and update the approved cross-reference list before the alternate enters the same bin. For LPA3 / LPW3 / LPW4, the drawing controls are 2 × M10 mounting positions, Ø126 mm mounting reference, Ø89 mm drive-end reference and 27 mm axial reference.

For LPA3 / LPW3 / LPW4, what dimensions should be checked before a commercial batch?

Within the Lister Petter interchange group, link the full LPA3 or LPW engine record to the Denso group, then compare eleven teeth, two M10 points, the Ø126 mm mounting reference, Ø89 mm drive end and 27 mm offset. For the 128000-8170 cross-reference decision, measure from the installation flange rather than an irregular housing edge and note whether holes are threaded or unthreaded. In the LPA3 / LPW3 / LPW4 stocking boundary, compare connection clearances as well as the front geometry. Within the Lister Petter interchange group, a signed old-unit or master unit check protects both the reseller and end user from a starter that is electrically correct but cannot be installed. The working scope is Lister Petter LPA3 and related LPW-series industrial engines, including selected Caterpillar-powered equipment records; it is not a universal statement for every Lister Petter machine.

For LPA3 / LPW3 / LPW4, how should mixed-reference RFQs be presented?

For this industrial-engine distributors, generator-service suppliers and compact-equipment rebuilders inquiry, place each full OE on its own line with the associated LPA3 / LPW3 / LPW4 or machine record, even when several numbers may cross to 128000-8170. When quoting 128000-8170, add quantity and photographs to each line. For the Lister Petter commercial request, the vendor can then cross-check which lines share the 11T physical version and which require separate master units, prices or packaging labels. A practical LPA3 / LPW3 / LPW4 inquiry includes engine model and build number, complete Denso or Lucas reference, equipment type, old-unit dimensions and electrical-terminal photographs.

For LPA3 / LPW3 / LPW4, what is the receiving release for this product?

At incoming inspection for 128000-8170, check the Lister Petter engine label, 11T pinion and broad triangular face; retain one measured master unit for generator and industrial-engine repeat orders. During the LPA3 / LPW3 / LPW4 lot release, extend the check to product labels, connections, pinion protection and carton integrity. For Lister Petter warehouse acceptance, inspect cartons from different pallet positions rather than only the top carton. At incoming inspection for 128000-8170, once the lot agrees with the signed unit, save photographs and inspection results with the 128000-8170 SKU before stock is made available to sales branches. The receiving release for this Lister Petter starter is the combined 11T, 2 × M10 mounting positions and terminal check.

For LPA3 / LPW3 / LPW4, what information speeds up a 128000-8170 quotation?

For the 128000-8170 supply program, provide engine model and build number, full Denso or Lucas reference, equipment type, old-unit dimensions and electrical-connection photographs, required quantity, destination, delivery target and packaging request. When preparing the LPA3 / LPW3 / LPW4 order, if the machine is immobilized, state whether an urgent master unit is needed. For this Lister Petter distributor line, clear application and physical data at the start lets Elecdura review the correct 12V, 2.0kW, 11T product instead of sending a low-confidence price for a broad cross-reference family. The LPA3 / LPW3 / LPW4 commercial request should retain 128000-8170, 12V, 2.0kW, 11T, quantity, destination and packaging preference on one line.

Request a 128000-8170 Starter Motor Wholesale Quote

Send engine model and build number, complete Denso or Lucas reference, equipment type, old-unit dimensions and electrical-terminal photographs, required quantity, destination and packaging preference. Elecdura will review the 12V, 2.0kW, 11T 128000-8170 configuration and confirm sample, lead-time and wholesale-supply details before the order is released.
