228000-2120 JS1089 Toyota Hilux Starter Motor 12V 2.0kW 10T

228000-2120 Starter Motor Wholesale Fitment Overview for Distributor Sourcing

Toyota buyers commonly encounter several Denso suffixes around the 228000-2120 family. The 12V, 2.0kW and 10-tooth configuration narrows the candidate, but it does not replace a check of the full label, drive-end casting and solenoid position.

For distributor stock, connect 228000-2120, JS1089, LRS02085 and Lester 33085 to one approved Toyota 2.4L diesel sample. Keep HiAce or Hilux model details and the 2L-series engine record with the inspection file so repeat orders do not drift into a nearby 9-tooth or different-power version.

228000-2120 Starter Motor B2B Production and Test Video for Bulk Procurement

This video introduces Elecdura starter-motor production and supply capabilities. Use the verified 228000-2120 / JS1089 specification and fitment controls on this page for product approval.

228000-2120 Starter Motor Distributor Specifications for Wholesale Supply

228000-2120 Starter Motor OE Cross-Reference Review for Aftermarket Buyers

The verified interchange group includes 228000-2120 through selected Denso suffixes, JS1089, LRS02085, Cargo 112336 and Lester 33085. Treat each suffix as a matching lead, then compare the nose housing, flange, terminal layout and 10-tooth drive before approval.

228000-2120 Starter Motor Bulk Fitment Approval for Fleet Procurement

A Toyota fleet buyer should identify the HiAce or Hilux platform, 2.4L diesel engine record and removed starter label. Measure the locating diameter and bolt spacing, photograph the drive end and rear terminals, and confirm that the 10-tooth pinion rests and engages at the same depth as the sample.

228000-2120 Starter Motor Receiving Inspection for Distributor Stock

At receiving, sample cartons across the lot and verify the Denso-family reference label, 12V marking, 2.0kW rating, 10-tooth pinion and approximately 36 mm gear diameter. Check terminal protection and nose-casting consistency, then isolate any suffix or housing that was not included in the signed approval.

228000-2120 Starter Motor MOQ and Private-Label Supply for B2B Orders

Toyota 2L-series orders can be packed neutrally or reviewed for private-label supply. The technical label must still retain the approved 228000-2120 / JS1089 identity, electrical rating and lot code so an importer can trace each claim back to the receiving sample.

228000-2120 Starter Motor Distributor FAQ for Bulk Procurement

Why must Toyota buyers keep the full 228000-2120 suffix?

Denso starters with similar housings may carry different suffixes, power ratings or drive details. Record every digit on the old label and compare it with 228000-2120, the accepted suffix group and JS1089. Then confirm the 12V, 2.0kW and 10-tooth configuration. This prevents a warehouse from treating a visually similar Toyota starter as an automatic interchange when its pinion position or terminal clocking is different.

Which Toyota application details make a JS1089 inquiry complete?

State whether the unit is for a HiAce or Hilux, provide the production year, 2.4L diesel engine or 2L-series code, and attach the removed starter label. Add photos of the mounting face, drive end and rear terminals. Those details let the supplier connect JS1089 to the correct Toyota variant instead of relying on a model name that may span several starter designs.

How should the 10T drive be checked before a bulk Toyota order?

Count all ten pinion teeth and measure the gear outside diameter, rest position and projected engagement depth. Compare the shaft, nose opening and ring-gear contact pattern with the approved unit. A 10-tooth count alone is not sufficient because nearby starters can use different offsets or flange geometry. Record these measurements with the sample so repeat lots follow the same mechanical standard.

Can a 12V Toyota starter with another power rating replace 228000-2120?

Do not approve a substitution from system voltage alone. The 2.0kW working rating, 10-tooth drive, rotation, mounting pattern and terminal arrangement must all agree with the removed unit. A lower-output version can produce slow cranking, while a different drive may damage the ring gear. Request a controlled sample and complete fitment check before changing the distributor purchase line.

What should be inspected when 228000-2120 cartons arrive?

Select samples from different cartons, not only the top layer. Check the complete reference label, 12V and 2.0kW markings, 10-tooth pinion, drive-end casting, mounting holes, terminals, protective caps and lot code. Compare the sample with the signed photos and dimensional record. Quarantine any mixed suffix, unexplained casting change or damaged terminal before the stock enters normal picking.

How can a workshop separate starter failure from a Toyota supply fault?

Measure battery state, cranking voltage and voltage drop on both positive and ground paths before condemning the starter. Confirm the start signal, engine mechanical load and ring-gear condition. A weak battery or corroded cable can imitate a failed 228000-2120. Keep the electrical readings, installation photos and old-unit label with a warranty claim so technical review starts from evidence rather than symptoms alone.

What packaging controls matter for JS1089 wholesale shipments?

The carton should prevent movement, nose impact and terminal bending while keeping the product reference and lot identity readable. For private-label orders, agree barcode, artwork, inner protection and carton strength before production. Do not remove the 228000-2120 / JS1089 traceability from the technical label, because the importer needs that identity for receiving checks, inventory control and later claims.

How should a distributor manage samples and repeat orders for 228000-2120?

Approve one marked sample before volume release when the fitment file is incomplete. Link the sample to the Toyota application, Denso suffix, drawing or measured dimensions and packaging revision. Repeat orders should cite the same approval record. If the supplier changes the nose casting, solenoid, pinion or production source, open a new revision instead of assuming the former sample still represents the shipment.

Which references should appear on a Toyota 228000-2120 RFQ?

Include 228000-2120 and all visible Denso suffixes, JS1089, LRS02085, 112336 or Lester 33085 when present. Also provide the Toyota model, 2L-series engine record, quantity, destination and target date. Clear old-unit photographs and drive measurements help the supplier quote one controlled configuration and reduce the risk of a low-price offer for the wrong starter.

Request a B2B Quote for 228000-2120 Starter Motors

Send the complete Denso label, Toyota model and 2L-series engine record, old-unit photos, required quantity and destination. Elecdura will review one defined 228000-2120 / JS1089 configuration for the quotation.
