228000-2970 New Holland L464 Ford 1920 Starter Motor Supply

228000-2970 Starter Motor Selection for Professional B2B Buyers

228000-2970 supports New Holland L464, L465, LX565 and related compact equipment plus selected Ford 1920 tractor applications. It is positioned for professional replacement supply where the buyer needs the correct unit to arrive, install and remain repeatable across later orders; the fixed electrical release is 12V, 2.0kW, 11T and CW.

Loader and tractor descriptions overlap across this family, but the purchasing record still needs the exact machine model and 11T Denso configuration rather than a generic New Holland label. A reliable order file should state exactly how the unit was separated from its neighbors: Identify the L464/L465/LX565 or Ford 1920 record, count eleven teeth, and compare the two Ø11 mm bores, Ø112 mm face, 21 mm axial reference and solenoid position.

228000-2970 Starter Motor Specification Matrix and Technical Drawing

For purchasing and inbound quality group, the key geometry is summarized in a single reference image below.

Identify the L464/L465/LX565 or Ford 1920 record, count eleven teeth, and compare the two Ø11 mm bores, Ø112 mm face, 21 mm axial reference and solenoid position. The image is a fitment reference and should be checked against the failed unit from the vehicle or buyer-approved reference piece rather than scaled from the screen.

228000-2970 New Holland / Ford Application Control for Wholesale Supply

Cross-reference breadth is useful only when it does not erase the version boundary. For 228000-2970, the principal buying identifiers include 228000-2970, 228000-5120, 228000-5121, 228000-5122, 228000-5123, while New Holland L464, L465, LX565 and related compact equipment plus selected Ford 1920 tractor applications defines the working application scope.

Identify the L464/L465/LX565 or Ford 1920 record, count eleven teeth, and compare the two Ø11 mm bores, Ø112 mm face, 21 mm axial reference and solenoid position. If any of those points disagree, quote the alternatives separately instead of presenting a broad universal-fit claim.

• Application limit: New Holland L464, L465, LX565 and related compact equipment plus selected Ford 1920 tractor applications.

• Mismatch control: Loader and tractor descriptions overlap across this family, but the purchasing record still needs the exact machine model and 11T Denso configuration rather than a generic New Holland label. Identify the L464/L465/LX565 or Ford 1920 record, count eleven teeth, and compare the two Ø11 mm bores, Ø112 mm face, 21 mm axial reference and solenoid position.

• Distributor traceability: agricultural and compact-equipment parts wholesalers managing mixed New Holland and Ford demand should retain 228000-2970, 228000-5120, 228000-5121, 228000-5122, 228000-5123 with the accepted physical comparison and customer requirement.

For New Holland / Ford compact tractor and skid-steer diesel sourcing, the retained geometry combines 2 × Ø11 mm mounting holes, Ø112 mm mounting reference, Ø74 mm drive-end reference and 21 mm axial reference. Additional service identifiers include 113696, 18139N, SBA185086530, STR5028. A quotation for this line should arrive with machine model and serial, Ford or New Holland reference, engine record, old starter label, mounting view and required quantity; that information lets agricultural and compact-equipment parts wholesalers managing mixed New Holland and Ford demand distinguish this configuration before stock is committed.

228000-2970 Starter Motor Warehouse Release and Order Support

Sample loader and tractor orders separately; verify 11T, mounting-ear spacing and pinion protection before combining accepted units into branch inventory. Add carton condition, terminal protection and pinion protection to the receiving record because transit damage can create the same customer downtime as a wrong fitment.

Commercial preparation includes sample confirmation, 20-piece starting MOQ, order-specific lead-time review and neutral or qualified private-label packing. The carton label should carry the exact OE and 11T configuration, not a broad brand-only description.

The embedded production video supports supplier qualification for wholesale programs. The commercial release for this item remains tied to 228000-2970, 12V, 2.0kW, 11T and the confirmed mounting arrangement.

228000-2970 Starter Motor FAQ for B2B Procurement

For compact tractor and skid-steer diesel, how should 228000-2970 be identified when the old label is damaged?

In the compact tractor and skid-steer diesel 228000-2970 identity file, use the compact tractor and skid-steer diesel engine or machine record, then photograph the drive end, flange face, side profile and cable points. For this New Holland / Ford number set, count the 11 teeth and measure the locating and axial references shown in the graphic. Within the 228000-2970 sourcing record, compare those details with 228000-2970, 228000-5120, 228000-5121, 228000-5122. In the compact tractor and skid-steer diesel 228000-2970 identity file, a damaged label increases the importance of the physical record; it does not justify a brand-only match. For the New Holland / Ford compact tractor and skid-steer diesel item, the usable identity chain is 228000-2970, 228000-5120, 228000-5121, 228000-5122.

For compact tractor and skid-steer diesel, which buying mistake is most likely with this starter?

For the compact tractor and skid-steer diesel fitment, loader and tractor descriptions overlap across this family, but the purchasing record still needs the exact machine model and 11T Denso configuration rather than a generic New Holland label. In this New Holland / Ford application, the control is to keep the application, fully stated OE, 12V, 2.0kW, 11T, mounting geometry and cable point layout on the same approval sheet. For the defined 228000-2970 scope, if one item is unknown, request it before the repeat-supply order rather than assuming the nearest visual match will install correctly. For compact tractor and skid-steer diesel, the version boundary is 11T, 2.0kW, Ø112 mm mounting reference and the complete OE group.

For compact tractor and skid-steer diesel, can the compact tractor and skid-steer diesel name be used as the only fitment field?

At the 11T drive check, the engine name is valuable, but it may be used in more than one machine or production version. For the 228000-2970 pinion review, combine it with the fully stated 228000-2970 or related OE, machine serial information and old-unit geometry. Within the compact tractor and skid-steer diesel drive record, identify the L464/L465/LX565 or Ford 1920 record, count eleven teeth, and compare the two Ø11 mm bores, Ø112 mm face, 21 mm axial reference and solenoid position. At the 11T drive check, that creates a controlled application boundary instead of an overly broad claim for every compact tractor and skid-steer diesel installation. The New Holland / Ford release uses 11T with CW rotation, so both details belong on the sample and carton checks.

For compact tractor and skid-steer diesel, why does 11T need to appear on the carton?

During mounting review for 228000-2970, tooth count is a visible warehouse control that separates this unit from neighboring products before installation. At the compact tractor and skid-steer diesel flange check, include 11T with 228000-2970 and 12V/2.0kW on internal labels and private-label artwork. For the New Holland / Ford installation comparison, inbound quality group should count the pinion on approval units and quarantine any carton whose product does not agree with the printed configuration. For compact tractor and skid-steer diesel, the drawing controls are 2 × Ø11 mm mounting holes, Ø112 mm mounting reference, Ø74 mm drive-end reference and 21 mm axial reference.

For compact tractor and skid-steer diesel, how are the mounting and terminal positions approved?

Within the New Holland / Ford interchange group, identify the L464/L465/LX565 or Ford 1920 record, count eleven teeth, and compare the two Ø11 mm bores, Ø112 mm face, 21 mm axial reference and solenoid position. For the 228000-2970 cross-reference decision, compare the starter taken from service and approval unit on a flat surface, using the flange face as the reference plane. In the compact tractor and skid-steer diesel stocking boundary, photograph battery and switch cable points from the same angle. Within the New Holland / Ford interchange group, keep the resulting images in the importer SKU record so later trade customers and warehouse staff can repeat the check without relying on memory. The working scope is New Holland L464, L465, LX565 and related compact equipment plus selected Ford 1920 tractor applications; it is not a universal statement for every New Holland / Ford machine.

For compact tractor and skid-steer diesel, what cross-reference discipline is recommended?

For this agricultural and compact-equipment parts wholesalers managing mixed New Holland and Ford demand inquiry, keep 228000-2970, 228000-5120, 228000-5121, 228000-5122 visible as fully stated strings throughout inquiry, quotation and approval unit review. When quoting 228000-2970, do not drop prefixes or suffixes to make a larger interchange group. For the New Holland / Ford commercial request, a reference joins the 228000-2970 stock line only when the application, 11T drive, electrical rating and mounting/cable point arrangement agree with the approval unit. A practical compact tractor and skid-steer diesel inquiry includes machine model and serial, Ford or New Holland reference, engine record, old starter label, mounting view and required quantity.

For compact tractor and skid-steer diesel, how should the lot be checked before customer dispatch?

At incoming inspection for 228000-2970, approval unit loader and tractor orders separately; inspect 11T, mounting-ear spacing and pinion protection before combining accepted units into branch inventory. During the compact tractor and skid-steer diesel lot release, inspect units from different cartons and record label accuracy, casting consistency, cable point protection and packaging condition. For New Holland / Ford warehouse acceptance, if the batch is for several branches, retain one accepted approval unit or a detailed photo set centrally. At incoming inspection for 228000-2970, this reduces disputes when a later return must be compared with the original release. The receiving release for this New Holland / Ford starter is the combined 11T, 2 × Ø11 mm mounting holes and terminal check.

For compact tractor and skid-steer diesel, which details should a B2B buyer send for pricing?

For the 228000-2970 supply program, send machine model and serial, Ford or New Holland reference, engine record, old starter label, mounting view and required quantity, quantity, destination, target delivery date and neutral or private-label preference. When preparing the compact tractor and skid-steer diesel order, put any alternate OE on a separate line and identify whether a approval unit must be approved. For this New Holland / Ford distributor line, this allows the quotation to cover both the commercial requirement and the exact 228000-2970 starter configuration rather than only a generic product name. The compact tractor and skid-steer diesel commercial request should retain 228000-2970, 12V, 2.0kW, 11T, quantity, destination and packaging preference on one line.

Discuss 228000-2970 Starter Motor Samples and repeat-supply order

Send machine model and serial, Ford or New Holland reference, engine record, old starter label, mounting view and required quantity, required quantity, destination and packaging preference. Elecdura will review the 12V, 2.0kW, 11T 228000-2970 configuration and confirm sample, lead-time and wholesale-supply details before the order is released.
