228000-6530 John Deere Tractor Starter Motor 12V 4.0kW 11T

228000-6530 John Deere Tractor Starter Motor B2B Supply for Aftermarket Buyers

228000-6530 gives aftermarket buyers a defined 12V, 4.0kW, 11-tooth clockwise configuration for John Deere tractors, combines and marine or industrial equipment using compatible 4045 diesel engines. Link the complete reference group to the buyer’s machine or engine record, then approve the mounting geometry, pinion position and terminal layout before releasing distributor stock.

228000-6530 Starter Motor B2B Production and Test Video for Fleet Replacement

This video introduces Elecdura starter-motor production and supply capabilities. Use the specification, cross-reference details and fitment checks on this page when evaluating 228000-6530.

228000-6530 Starter Motor Distributor Specifications for Wholesale Supply

228000-6530 Starter Motor OE Cross-Reference Review for Distributor Sourcing

Use 228000-6530 as the primary purchasing reference and cross-check RE501298, RE529593, SE501403, 18018. These numbers identify the candidate starter family, but approval still requires the exact suffix, electrical rating, drive end, mounting geometry, pinion and terminal layout to match the removed unit or signed sample.

228000-6530 Starter Motor Bulk Fitment Approval for Bulk Procurement

Fitment control for 228000-6530 starts with the old starter and the application record. Compare tractor or machine model, engine plate, bell-housing pattern, pinion reach and terminal orientation, and do not force a unit into position with the mounting bolts. If the reference family includes multiple ratings or tooth counts, create separate approval and inventory records for each physical version.

228000-6530 Starter Motor Wholesale Receiving Inspection for B2B Supply

Inspect incoming 228000-6530 lots against the signed sample and purchase-line specification. Check rating label, tooth count, mounting face, corrosion protection, terminals and lot marking, record the result by lot and quarantine any mixed version before it reaches saleable inventory. This prevents a low-cost receiving shortcut from becoming a wrong starter during planting or harvest can cost far more than the unit price in lost operating hours.

228000-6530 Starter Motor MOQ and Private-Label Supply for Aftermarket Buyers

228000-6530 Starter Motor Distributor FAQ for Fleet Replacement

How should warranty evidence be prepared for 228000-6530?

The standard warranty is 18 months under agreed sales terms, but a claim still needs traceable supporting evidence. Record the invoice or lot, installed application, old and supplied references, installation date, symptoms and electrical test results. Include photographs of the unit, terminals, mounting and pinion. Do not dismantle or discard the product before instructions are agreed. Complete supporting evidence speeds technical review and prevents a battery, wiring or ring-gear problem from being misclassified.

How should 228000-6530 cross-references be controlled in a B2B order?

Use 228000-6530 as the control reference and compare the complete group 228000-6530 / RE501298 / RE529593 / SE501403 / 18018. A cross-reference narrows the candidate, but it does not prove that every suffix has the same rating or mounting. Keep the removed-unit label, drive-end photograph, mounting-face view and rear-terminal view in the approval file, then connect that evidence to one RFQ and order line so repeat orders remain traceable.

What engine or equipment data is required for 228000-6530?

Confirm the complete 228000-6530 / RE501298 / RE529593 / SE501403 / 18018 group together with the 12V, 4.0kW, 11-tooth clockwise configuration. Similar appearance or a shared partial number is not enough; compare tractor or machine model, engine plate, bell-housing pattern, pinion reach and terminal orientation against the removed unit or approved sample and keep the signed sample with the purchase record.

Why must 12V, 4.0kW and 11T be checked together on 228000-6530?

Confirm the complete 228000-6530 / RE501298 / RE529593 / SE501403 / 18018 group together with the 12V, 4.0kW, 11-tooth clockwise configuration. Similar appearance or a shared partial number is not enough; compare tractor or machine model, engine plate, bell-housing pattern, pinion reach and terminal orientation against the removed unit or approved sample and keep the signed sample with the purchase record.

What must be approved before volume supply for 228000-6530?

Confirm the complete 228000-6530 / RE501298 / RE529593 / SE501403 / 18018 group together with the 12V, 4.0kW, 11-tooth clockwise configuration. Similar appearance or a shared partial number is not enough; compare tractor or machine model, engine plate, bell-housing pattern, pinion reach and terminal orientation against the removed unit or approved sample and keep the signed sample with the purchase record.

How can a buyer prevent a bolt-up mismatch on 228000-6530?

Compare the tractor or machine model, engine plate, bell-housing pattern, pinion reach and terminal orientation with the removed starter. Check bolt-hole spacing, locating diameter, starter clocking, pinion rest position and rear-terminal clearance instead of judging from the outer housing alone. Never pull a misaligned unit into place with mounting bolts. A measured or photographed fitment record is especially valuable when nearby references share the same voltage and tooth count but use another drive-end or solenoid orientation.

How should a wholesale shipment of 228000-6530 starters be inspected?

Tie every carton and sampled unit to 228000-6530, the approved cross-reference set and the supplier lot. Inspect rating label, tooth count, mounting face, corrosion protection, terminals and lot marking, then compare the sampled unit with the signed photos or dimensional record. Record pass and fail quantities before the stock is mixed. Quarantine any different rating, pinion, mounting face or terminal layout, because a wrong starter during planting or harvest can cost far more than the unit price in lost operating hours. This receiving discipline is cheaper than sorting returns after distribution.

When is a cross-referenced substitute acceptable for 228000-6530?

A substitute is acceptable only when its complete OE relationship, 12V system, 4.0kW rating, 11T, rotation and mounting geometry agree with the approved unit. Similar appearance or a shared partial number is not enough. Ask for application and old-unit evidence, then test or approve a sample prior to changing the purchase line. Retain materially different versions separate in inventory so warehouse staff cannot fulfil one inquiry with the wrong variant.

Which system checks should precede a 228000-6530 warranty claim?

Inspect battery load condition, ground path, safety-start circuit, cable drop and ring-gear wear before condemning the starter. Record battery voltage at rest and during the start command, then measure voltage drop under load; a weak supply or poor ground can imitate starter failure. Inspect the mounting surface and gear engagement as well. Attach these results, the old-unit label and failure symptoms to the claim so the supplier can distinguish a product defect from an upstream electrical or mechanical problem.

Request a B2B Quote for 228000-6530 Starter Motors

Send the complete reference, John Deere tractors, combines and marine or industrial equipment using compatible 4045 diesel engines, old-unit photos, quantity, destination and packaging or inspection requirements. Elecdura will use that evidence to review one defined aftermarket starter configuration for your quotation.
