428000-2590 Case LW780 10T Starter Motor Wholesale

428000-2590 Case LW780 Starter Motor for Equipment Distributors

A wheel loader waiting for a starter can stop loading, yard or site work, making response time as important as unit price. State the LW780 model, machine serial and delivery destination so Elecdura can discuss the 428000-2590 match, available timing and suitable transport protection in one reply.

The broader 428000-2590 and 8605784 reference family appears beside other Case and New Holland equipment. Before treating it as interchangeable, compare the 10T drive, three Ø12 holes, 89 mm engagement and terminal clocking with the starter removed from the specific loader.

428000-2590 Case 24V 7.8kW Starter Motor Specifications

The required combination is 24V, 7.8kW, 10T, module 3.175 and clockwise rotation. For an equipment fleet, keep the full set on the purchasing line so a lower-output or different-pinion starter is not selected during an urgent repair.

428000-2590 Case LW780 Starter Motor Dimensions for Distributor Orders — compare the drawing with the removed starter before placing a volume order.

The dimensional checkpoints are three Ø12 mounting holes on the Ø127 circle, engagement C of 89 mm and distance H of 27 mm. Include one front photograph and one side photograph with the measuring points visible; this is more useful than a distant installed view.

428000-2590 Case LW780 Mounting and Reference Review

428000-2590, 428000-2591, 428080-2591, Case 8605784 and 19515N form the working search group. A complete enquiry should still name LW780 and show the old drive end because a cross-reference list does not reveal every housing or terminal variation.

For several loaders, list quantity by machine model and site, especially where equipment histories include repaired or remanufactured starters. Once the removed units agree physically, the buyer can consolidate one order while retaining site-level demand for emergency-stock and replenishment decisions.

428000-2590 Starter Motor Supply for Loader Uptime

Receiving teams should sample cartons from different pallet positions, count 10 teeth, inspect the three mounting points and check studs for impact. Record the shipment lot and accepted images before distributing units to remote sites where a wrong starter would create another equipment stoppage.

The Elecdura video introduces starter-motor assembly and electrical testing for B2B programs. Case equipment suppliers can review that capability together with first-lot inspection, export packing, destination labels and replenishment timing for wheel-loader service.

428000-2590 Starter Motor FAQs for B2B Buyers

Why should the Case LW780 serial be included with 428000-2590?

Machine serial information helps distinguish the actual wheel-loader installation from the wider 8605784 reference family. Add the old-starter label and front, side and terminal photographs. Elecdura can then discuss the 10T 7.8kW product, delivery urgency and quantity without assuming every Case machine listed beside the reference uses the same construction.

How are engagement C and distance H used for the LW780 starter?

Measure the 89 mm engagement C and 27 mm distance H from a trusted removed starter using the same points shown in the drawing. Include a side photograph with the measuring direction visible. These values describe the drive position and help separate 428000-2590 from a similar high-output starter with another nose or pinion location.

Which flange measurements identify the Case 428000-2590 product?

Compare all three Ø12 mounting holes and the Ø127 hole-circle reference from a square front view. Check that the locating face seats correctly and that the ears have not been repaired. Use these measurements together with the 10T pinion; a matching circle alone does not prove that the drive and terminals suit the loader.

How should a loader breakdown request be presented to the supplier?

State whether the LW780 is stopped, the number of supported machines, the observed failure and the exact delivery point. Include battery and cable test results plus the removed-starter photographs. This gives Elecdura enough technical and commercial context to respond with the right 428000-2590 product, realistic timing and suitable freight protection.

Does Case 8605784 automatically confirm 428000-2590 fitment?

8605784 is a useful reference route, but it should stay with the LW780 machine, 10T pinion, three-hole face and C/H dimensions. The wider number group appears beside other equipment. Confirming the physical checkpoints before ordering lets distributors use cross references for search without treating them as a universal installation guarantee.

How can a distributor set reserve stock for remote loader sites?

Count active LW780 loaders by site, review recent starter usage and compare the result with transport and replenishment time. Keep an emergency quantity separate from normal branch stock. Store the accepted 428000-2590 images with the item so urgent dispatch staff can identify the 10T configuration without opening or measuring every carton.

What should receiving inspect before releasing a Case starter shipment?

Sample cartons from more than one pallet area, count the 10T pinion and compare the three mounting points, nose and terminal clocking with accepted images. Inspect studs and locating surfaces for impact. Record the shipment lot and sampled electrical result so remote branches and after-sales teams share the same incoming baseline.

What will Elecdura need for a Case LW780 distributor quotation?

Provide the machine model and serial, complete old-unit numbers, measured C/H values, clear pinion, mounting and terminal views, quantity, required date and destination. Elecdura will review the 428000-2590 product and respond with matching feedback, price basis, supply timing, packing and delivery terms appropriate for construction-equipment service.

Request 428000-2590 Case LW780 Starter Motor Pricing

Send the Case LW780 model and serial, 8605784 or other complete reference, square mounting, pinion and terminal photographs, quantity by destination and required date to info@elecdurauto.com. Elecdura will review 428000-2590 and return practical pricing, packing and supply-time information.
