428000-6900 John Deere Starter Motor 24V 5.5kW 10T

428000-6900 Agricultural Machinery Starter Motor for JOHN DEERE 210

For aftermarket wholesalers planning mixed-model inventory, 428000-6900 gives agricultural-machinery distributors, importers and engine-parts wholesalers a defined aftermarket starter motor for JOHN DEERE 210. The supplied version combines 24V, 5.5kW and 10T for OE-reference matching, wholesale quotation and repeat purchasing.

For sourcing managers confirming an incoming batch, importers can use the same reference and specification bundle from enquiry through receiving. That continuity helps sales, purchasing and warehouse teams keep a repeat-order item separate from similar housings with another electrical or drive configuration.

428000-6900 Starter Motor Specifications and Technical Drawing

For maintenance suppliers preparing an OE-based quote, because no dimensional drawing is available for this version, the approved product views, full reference and 24V 5.5kW 10T specification should be compared with the starter being replaced. Customer measurements can then complete the fitment review without introducing unverified dimensions.

For equipment-parts dealers separating similar housings, A dimensional drawing was not supplied for 428000-6900. For a fitment enquiry, provide straight-on images of the mounting face and drive end plus the locating diameter, hole spacing, pinion projection and terminal direction measured from the starter being replaced.

428000-6900 Aftermarket Replacement and Application

For application specialists checking version-defining data, send 428000-6900, the full JOHN DEERE 210 description and photos of the starter being removed. These details allow the quotation to stay product-specific when related numbers appear on more than one housing version.

For replacement-parts sellers confirming electrical ratings, the starter being replaced should agree with the approved drive-end, side and rear views. Confirm the 10T pinion and module 3, then keep any different flange or terminal layout outside the current quotation line.

428000-6900 Wholesale Supply for Distributors and Importers

For warehouse planners setting packaging requirements, 428000-6900 is available for professional aftermarket supply to agricultural-machinery distributors, importers and engine-parts wholesalers. Ask for wholesale pricing with quantity, destination and packaging requirements; standard terms are 20 pcs MOQ, 7–15 days after confirmation and 18 months warranty.

For importers planning replenishment, define the reference group, accepted product version, inspection request and packaging standard before production. Those records help both sides manage replenishment and resolve any receiving question efficiently.

428000-6900 Starter Motor Buyer FAQ

Which check should lead 428000-6900 before stock is assigned?

For engine-parts specialists confirming electrical ratings, 428000-6900 should be treated as one inquiry group only after the unit in hand is compared. Ask the customer for the complete label and clear views of the drive end, flange and terminals. If a suffix, housing shape or terminal clocking differs, keep it as a separate RFQ entry instead of assuming that the shared number guarantees interchangeability.

How should a workshop distinguish 10T and module 3 for warehouse identification?

For fleet-parts buyers checking repeat-order specifications, the supplied drive uses 10 teeth with module 3. Count the old pinion teeth and compare outside diameter, rest position and engagement depth at inquiry stage. The 3 module is part of the gear definition, so another pitch must not be combined on the one stock line. This check protects the ring gear from an incorrect mesh.

What must be matched before quoting 428000-6900 cartons and units for a documented fitment decision?

For aftermarket wholesalers planning replenishment, sample cartons from different positions in the shipment and compare the 428000-6900 labels, 24V marking, 10-tooth pinion, flange shape and terminal protection with the order specification. Photograph any mixed marking, damaged terminal or different drive end prior to fitting, and isolate those pieces so the rest of the lot can be assessed consistently.

What should purchasing verify first for axial reach for repeatable sourcing?

For fitment reviewers checking application evidence, the source drawing does not provide a complete axial length for 428000-6900. Ask for measured pinion rest position, flange-to-drive distance and a square side photograph of the old unit. Keep those customer measurements with the 10T drive definition so an unstated length is not borrowed from a neighboring reference.

Which check should lead 428000-6900 drive-end photograph when checking a replacement proposal?

For application specialists preparing an OE-based quote, the drive-end image for 428000-6900 should be used to count 10 teeth and compare the flange, locating shoulder and pinion rest position. Use a matching frontal view of the starter being replaced. A poorly aligned photo can obscure drive and flange details; request another image before approving a near-match.

Which comparison prevents a mismatch for 24V system compatibility for a first stocking order?

For replacement-parts sellers separating similar housings, 428000-6900 is a 24V starter and must be connected only to the matching machine electrical system. Read the voltage marking on the old unit and verify the battery arrangement prior to purchase. A housing can look correct while the winding and solenoid are designed for another voltage, so appearance must not override the electrical label.

How should a workshop distinguish mounting face, locating shoulder and bolt positions before a purchase order is released?

For service-parts networks evaluating a direct replacement, no dimensional drawing is supplied, so measure the old unit's mounting face, locating shoulder and bolt positions. Take each measurement from the same face shown or described, then compare the locating shoulder, bolt pattern and drive-end projection as one set. A single matching diameter is not enough if the hole pattern or axial reach places the pinion differently.

How can a buyer screen 428000-6900 inquiry package when the unit taken from service is available?

For importers confirming commercial terms, A useful inquiry for 428000-6900 includes quantity, destination, required date, JOHN DEERE 210, the full old-unit number and clear photos of the label, drive end, front housing and terminal arrangement. State neutral or private-label packaging needs at the same time. Elecdura can then quote the 24V, 5.5kW, 10T version against one unambiguous product description.

Request a Wholesale Quote for 428000-6900 Agricultural Machinery Starter Motor

For inventory buyers reviewing customer demand, provide 428000-6900, JOHN DEERE 210, expected order quantity and destination. Include photos or measurements when the unit taken from service differs in suffix or mounting appearance, and Elecdura will review the correct version before pricing.
