TG228000-9151 John Deere Starter Motor 24V 5.5kW 11T

TG228000-9151 Agricultural Machinery Starter Motor for JOHN DEERE

For importers planning mixed-model inventory, this agricultural machinery starter motor serves JOHN DEERE replacement demand under reference TG228000-9151. Its 24V system, 5.5kW rating and 11T drive help importers and distributors identify the required version before discussing volume supply.

For inventory buyers confirming an incoming batch, this page is designed to support a distributor decision: identify the correct replacement, confirm the key specification, define packaging and inspection needs, and request one consistent quotation for the required quantity.

TG228000-9151 Starter Motor Specifications and Technical Drawing

For engine-parts specialists preparing an OE-based quote, because no dimensional drawing is available for this version, the approved product views, full reference and 24V 5.5kW 11T specification should be compared with the starter being replaced. Customer measurements can then complete the fitment review without introducing unverified dimensions.

For fleet-parts buyers separating similar housings, A dimensional drawing was not supplied for TG228000-9151. For a fitment enquiry, provide straight-on images of the mounting face and drive end plus the locating diameter, hole spacing, pinion projection and terminal direction measured from the starter being replaced.

TG228000-9151 Aftermarket Replacement and Application

For maintenance suppliers checking version-defining data, use TG228000-9151 as the primary product identity for JOHN DEERE. The cross-reference group TG228000-9151, RE504245 supports aftermarket matching, while the electrical rating and drive-end configuration distinguish the exact version supplied here.

For equipment-parts dealers confirming electrical ratings, use the gallery to compare the flange, 11T pinion and rear connections before approving the order. Keep module 3 with the tooth count. A changed mounting or terminal feature should be quoted as another starter version.

TG228000-9151 Wholesale Supply for Distributors and Importers

For purchasing teams setting packaging requirements, Elecdura supports repeat-order and new-line sourcing for TG228000-9151. Commercial planning can cover a 20 pcs MOQ, 7–15 day lead time subject to confirmation, neutral packaging or private-label review, and an 18-month agreed warranty.

For distributors planning replenishment, the order specification may include armature, solenoid, no-load or load testing together with label and packaging requirements. This gives receiving teams practical points for sampling a batch without treating appearance alone as proof of fitment.

TG228000-9151 Starter Motor Buyer FAQ

How should a workshop distinguish TG228000-9151 locating face before an installation slot is booked?

For replacement-parts sellers confirming electrical ratings, the TG228000-9151 flange should sit flat against the JOHN DEERE mounting surface without being pulled into place by the bolts. Clean both faces and compare the locating shoulder, hole pattern and any stated diameters. Rocking, a visible gap or bolt misalignment indicates that the version check is incomplete and installation should stop.

Which detail separates module 3 before accepting a substitute?

For service-parts networks checking repeat-order specifications, module 3 is part of the gear geometry for TG228000-9151. Confirm it together with the 11-tooth count and pinion diameter; another module changes tooth pitch even when the number of teeth is unchanged. The old starter or ring-gear specification should therefore support the module match before a substitute is accepted.

Which specification deserves priority for TG228000-9151 without a supplied drawing for warehouse identification?

For importers matching the starter removed from the machine, because this item has no supplier dimensional drawing, send straight-on photographs of the mounting face and drive end with a ruler or caliper reference. Include bolt-hole spacing, locating diameter, pinion projection and terminal orientation. Elecdura can then review the same physical points before quoting, without inventing dimensions that are not stated for TG228000-9151.

How should a workshop distinguish JOHN DEERE before an installation slot is booked?

For product managers checking application evidence, JOHN DEERE identifies the intended agricultural or industrial machine family, but it should not be used by itself. Pair the application with TG228000-9151, the 24V electrical system and the 11-tooth drive. That combination lets purchasing exclude nearby versions used on another engine build, chassis revision or equipment configuration ahead of commercial and delivery confirmation.

Which specification deserves priority for 5.5kW output on JOHN DEERE before a purchase order is released?

For maintenance suppliers preparing an OE-based quote, the 5.5kW rating belongs to the TG228000-9151 configuration used for JOHN DEERE. Verify the old-unit rating and investigate battery voltage, cable drop and engine turning resistance before choosing another output. A higher or lower kW figure is not an automatic upgrade; it can indicate a separate starter design with different electrical and mechanical requirements.

What must be matched before quoting TG228000-9151 replenishment before comparing delivery options?

For private-label buyers requesting production pricing, keep TG228000-9151, 24V, 5.5kW, 11T, the application description and the agreed packaging on the same replenishment line. Add dated photos when the equipment fleet changes or a different old starter appears. This gives purchasing and warehouse teams enough detail to avoid silently merging a new version into established stock.

What should purchasing verify first for mounting face, locating shoulder and bolt positions before a purchase order is released?

For purchasing teams evaluating a direct replacement, no dimensional drawing is supplied, so measure the old unit's mounting face, locating shoulder and bolt positions. Take each measurement from the same face shown or described, then compare the locating shoulder, bolt pattern and drive-end projection as one set. A single matching diameter is not enough if the hole pattern or axial reach places the pinion differently.

What should purchasing verify first for TG228000-9151 ring-gear engagement when checking a replacement proposal?

For distributors comparing the flange and terminals, review the 11T pinion, module 3, rest position and available axial dimensions as one engagement set. Inspect the ring gear for wear before fitting. A correct bolt pattern cannot protect the gear if pitch or projection differs, so drive geometry should be resolved before the starter is energized.

Request a Wholesale Quote for TG228000-9151 Agricultural Machinery Starter Motor

For aftermarket product managers reviewing customer demand, prepare the RFQ with TG228000-9151, RE504245, the complete application, quantity, target delivery and packaging requirements. We will respond with the defined 24V 5.5kW 11T starter motor line rather than a generic substitute.
