OE-Equivalent Replacement Quality
IATF 16949 / ISO 9001 / CE / RoHS
50 pcs
7 - 15 Days
12 Months
6359424
HydraForce size 10 hydraulic cartridge valves using 6359424 and the matching Weatherpack connector
Confirm 24v, 14w, weatherpack connector, coil bore and retaining method before installation.
| Quantity: | |
|---|---|
6359424 is a hydraulic solenoid valve coil for HydraForce size 10 hydraulic cartridge valves using 6359424 and the matching Weatherpack connector. Buyers should confirm the full reference, 24v, weatherpack connector, coil bore and body construction before approving replacement stock.
Specification | Confirmed Information |
|---|---|
Product Type | Hydraulic Solenoid Valve Coil |
Primary Reference | 6359424 |
Cross References | 6359424 |
Voltage | 24V |
Power | 14W |
Connector | Weatherpack connector |
Insulation Class | F/H |
Application Scope | HydraForce size 10 hydraulic cartridge valves using 6359424 and the matching Weatherpack connector |
MOQ | 50 pcs |
Delivery Time | 7 to 15 Days |
Warranty | 12 Months |
Complete every control point below before a sample or bulk order is released.
Approval Point | Buyer Review |
|---|---|
Reference | 6359424 |
Electrical | 24V; 14W; verify under load |
Connector | Weatherpack connector |
Mechanical | Compare bore, height, body shape and retaining method |
Machine Evidence | HydraForce size 10 hydraulic cartridge valves using 6359424 and the matching Weatherpack connector |
Separate electrical command, component movement and final machine response so the actual wiring or hydraulic fault is not hidden by parts replacement.
Observed Condition | Recommended Check |
|---|---|
No magnetic pull | Check loaded voltage, ground, continuity and coil resistance. |
Intermittent operation | Inspect terminal retention, lead damage and heat-related winding faults. |
Excessive heating | Confirm voltage, wattage, duty cycle and free valve-stem movement. |
Connector damage | Inspect keying, seals, corrosion and harness side loading. |
Correct coil, no hydraulic response | Inspect the armature, spool, oil cleanliness and machine command. |
When a return analysis starts without machine records, keep the verified measurements and test result in the service record. Approve the complete old marking, 24v rating, 14w power reference, weatherpack connector, coil bore, body height and retaining method. A matching voltage alone does not prove fit. Send straight-on connector, top-bore and side-profile photographs with measurements so the replacement is selected from electrical and mechanical evidence.
When a warm hydraulic system develops slow response, keep the verified measurements and test result in the service record. Measure voltage directly across the energized coil while the machine issues the real hydraulic command. An unloaded harness reading can hide resistance at a corroded terminal, relay or ground path. Compare the loaded result with 24v, record polarity where suppression is present and correct the circuit before blaming a new coil for weak magnetic pull.
When a serial-controlled overhaul is planned, keep the verified measurements and test result in the service record. Power affects current draw, heat generation and available magnetic force. A replacement with another wattage may fit the valve stem yet operate too weakly, run hotter or exceed a controller output. Confirm 14w from the old label or approved specification, then compare warm current and temperature during sample testing before releasing a bulk order.
When a fleet contains two similar coil versions, keep the verified measurements and test result in the service record. Compare pin count, key position, latch direction, cable exit, terminal size and seal arrangement. Similar coil bodies may use a Deutsch, Weatherpack, insert or lead-wire connection that is not electrically or mechanically interchangeable. Photograph the connector face beside a ruler and note any diode or polarity marking before purchasing or adapting the harness.
When an emergency field repair is reviewed, keep the verified measurements and test result in the service record. A plain winding may operate with either polarity, but a coil containing a diode or other suppression device can be polarity-sensitive. Reversed connection may prevent correct operation or damage the suppression component. Check markings and the equipment schematic before applying power, and keep pin assignments with the approved sample and production inspection record.
When an old label is partly unreadable, keep the verified measurements and test result in the service record. Provide the complete old marking, measured voltage, connector-face photograph, bore and height dimensions, power reference, valve or machine application, quantity and destination. If the label is missing, include current draw and clear views from every side. This evidence allows technical approval and commercial quotation to proceed together without relying on appearance alone.
When a valve body was replaced during an earlier repair, keep the verified measurements and test result in the service record. Install one sample on the correct valve stem, confirm connector engagement and retaining clearance, then record cold current, warm current, operating temperature and hydraulic response through several command cycles. Compare results with the removed coil. Retain the approved sample and test sheet so later lots can be inspected against the same acceptance criteria.
Send the complete old marking or component evidence, confirmed voltage, machine information, clear photos, measurements and required quantity for a fitment-focused B2B quotation.
