Elecdura
Available for qualified orders
20 pcs
7 - 15 Days
Neutral packaging / private-label review
18 Months
0-24000-3030
Isuzu 6HH1; 24V, 4.5kW, 11T
Confirm 11T pinion, mounting face, drive reach, solenoid position and terminal orientation, 24V, 4.5kW, solenoid position and terminal layout against the removed starter before volume supply.
| Quantity: | |
|---|---|
This 0-24000-3030 product line for Isuzu 6HH1 is aimed at B2B buyers handling starter demand. The 24V, 4.5kW, 11T specification helps separate this configuration from related units when several similar starters pass through the same parts counter.
Regional parts dealer teams handling consolidated shipment should send 0-24000-3030, the Isuzu 6HH1 record, required quantity, destination and delivery timing together. Add straight drive-end and terminal-side photographs of the removed starter. Elecdura can then address clear lot-to-lot comparison, repeat-order carton marks and the correct physical configuration in one useful commercial offer.
| Primary order identity | 0-24000-3030 |
| Target application | Isuzu 6HH1 |
| Starter design | Nikko-type replacement |
| System voltage | 24V |
| Rated output | 4.5kW |
| Pinion identification | 11T / confirm dimensions from the removed unit |
| OE / reference group | 0-24000-3030 |
| Wholesale terms | MOQ 20 pcs / normally 7–15 days after order confirmation |
| Warranty | 18 months under agreed sales terms |
Receiving and technical teams should concentrate on 11T pinion, mounting face, drive reach, solenoid position and terminal orientation. A square drive-end image plus a side image gives a much clearer comparison of mounting, locating and pinion relationships than a general product shot, reducing the chance of releasing a visually similar but unsuitable unit.
Confirm the machine system as 24V and retain the 4.5kW, 11T specification on the RFQ. Check that the main cable and control lead can reach their studs without tight bends or interference, especially where the starter sits close to engine or frame components.
For repeat supply, store 0-24000-3030, Isuzu 6HH1, the received lot and the confirmed old-unit photographs together. That record allows a distributor to reorder the same configuration without rebuilding the decision from a loose list of aftermarket numbers.
For consolidated shipment, keep 0-24000-3030, Isuzu 6HH1, 24V, 4.5kW and 11T on one purchasing record. At goods-in, review old-unit photo linkage before releasing the lot. This gives the regional parts dealer a documented basis for clear lot-to-lot comparison when the next order is raised.
Distributor quotations can separate sample validation, regular replenishment and urgent service demand. Once the exact product and quantity are confirmed, Elecdura provides packing, lead-time and shipping terms; standard supply is 20 pieces minimum with an 18-month warranty under agreed conditions.
Demand from a fleet powertrain store should keep 0-24000-3030 tied to Isuzu 6HH1. For consolidated shipment, the regional parts dealer can use a machine-down contingency stock, keep the flange measurement sheet and review old-unit photo linkage at goods-in. This supports clear lot-to-lot comparison while keeping repeat-order carton marks visible.
The video below introduces Elecdura starter-motor production and electrical testing for B2B supply. Buyers can review factory capability while using the 0-24000-3030 application and specification shown above for their own product comparison.
Regional parts dealer teams should tie 0-24000-3030 to Isuzu 6HH1, 24V, 4.5kW, 11T and the removed-unit photographs before requesting price. For consolidated shipment, state quantity, destination and delivery timing, then review old-unit photo linkage. Ask Elecdura to address repeat-order carton marks and clear lot-to-lot comparison in the same quotation.
Low battery capacity, excessive voltage drop, corroded lugs, weak grounds, undersized cables and mechanical engine drag can all reduce cranking speed. Record loaded battery voltage and cable-drop readings before replacement. This protects the buyer from changing a starter while the original circuit problem remains. Retain 0-24000-3030 for clear lot-to-lot comparison and receiving review.
Tell Elecdura the quantity, destination, required arrival date and whether the demand supports an urgent repair, normal replenishment or a planned project. Normal preparation is 7–15 days after confirmation, but freight and packing choices depend on the actual schedule and shipment size. Keep 0-24000-3030 traceable through consolidated shipment.
Load-test the battery, measure voltage drop on positive and ground circuits, inspect cable lugs and confirm the engine turns freely. Check the ring gear and mounting-ground contact as well. These steps help separate a starter concern from weak batteries, high resistance or mechanical drag that can produce similar symptoms. File 0-24000-3030 with the old-unit photo linkage check.
Use the full reference, Isuzu 6HH1 application and core specification on the internal item label. Store the confirmed product photographs with the ERP record and avoid abbreviating the number. Receiving staff can then compare each new lot with the same documented configuration before distributing it to branches. Retain 0-24000-3030 for clear lot-to-lot comparison and receiving review.
Neutral packaging is available, and private-label requirements can be reviewed for qualified orders. Send the expected quantity, artwork, label fields, carton preference and destination early. Elecdura will confirm what can be supported, any additional preparation and the effect on lead time before the order is finalized. Retain 0-24000-3030 for clear lot-to-lot comparison and receiving review.
Send the complete 0-24000-3030 reference, Isuzu 6HH1 details, quantity, destination and required date. Add clear front, side and terminal photographs of the removed starter. This gives Elecdura enough information to discuss the intended 24V 4.5kW 11T unit, packing, lead time and freight in one focused offer. Carry the 0-24000-3030 result into repeat-order carton marks.
Provide the invoice or lot reference, installation date, Isuzu 6HH1 details, service time and a clear description of the symptom. Include photographs of the flange, drive and terminals plus battery and voltage-drop results. Keep the unit assembled until Elecdura confirms the next step under the agreed terms. Link 0-24000-3030 photographs to the old-unit photo linkage record.
Email info@elecdurauto.com with 0-24000-3030, Isuzu 6HH1 details, old-unit photographs, quantity, delivery country and required date. Elecdura will reply with the matching 24V 4.5kW 11T offer, availability, packing, lead time and freight options.
