S0610S 0001108228 Audi VW Starter Motor 12V 1.4kW 9T

S0610S 0001108228 Starter Motor for Audi and Volkswagen Supply

This S0610S aftermarket starter is prepared for selected Audi A8 and Volkswagen Phaeton or Touareg applications where the 12V, 1.4kW, 9-tooth and clockwise configuration matches the removed unit. Reference numbers identify the candidate; the engine code, locating diameter, mounting face, pinion and terminal layout control final approval.

Elecdura Starter Motor Supply Overview

S0610S Starter Motor Specifications

Audi and Volkswagen Application and Cross-Reference Review

Application lists narrow the search; they do not replace OE and physical matching. Confirm the vehicle production date and engine code before treating any year range as final fitment.

Before-Order Matching Checks for S0610S

Control Total Procurement Cost, Not Only Unit Price

A lower unit price does not offset mixed ratings, fitment returns, emergency freight, workshop labor or lost customer confidence. Approve one traceable sample, record the critical references and geometry, and require batch receiving checks against that baseline. If the supplier, material, internal design or production source changes, the approved evidence should be reviewed before the next shipment is released.

Wholesale Supply Information

S0610S Audi Volkswagen Starter Motor FAQ

Which references should be matched to S0610S before ordering?

Use S0610S as the public aftermarket reference and compare the removed starter with Bosch 0001108207, 0001108228, 0001108229 or 0986027480 and VAG 07C911023D, 07C911023F or 07C911023FX where applicable. WAI 19003N is another useful market cross-reference. A number match identifies a candidate, but the buyer should still retain the old label, drive-end photo, mounting face, rear terminals and vehicle record before releasing a bulk order.

Which Audi and Volkswagen applications are associated with this starter family?

Verified listings connect this reference group with selected Audi A8 D3 6.0 W12 quattro applications and Volkswagen Phaeton 6.0 W12 or Touareg 6.0 W12 and 4.2 V8 FSI applications. Year and engine coverage varies by model and catalog. Confirm the complete VAG or Bosch number, vehicle model, production date, engine code and the removed starter's physical configuration. Do not approve fitment from the words Audi, Volkswagen or W12 alone.

Why should the mounting pattern be checked even when the OE number matches?

Catalogs can count mounting and threaded holes differently, and closely related starters may share broad cross-references while using another flange or clocking arrangement. Compare the 74 mm locating diameter, each mounting position, threaded versus unthreaded locations, installed clearance and solenoid orientation with the removed unit. A starter that appears similar but does not seat correctly should never be pulled into position with the bolts, because misalignment can damage the housing, pinion engagement or ring gear.

Can a 1.7kW starter be substituted for this 1.4kW S0610S configuration?

Not automatically. This Elecdura item follows the supplied catalog configuration of 12V and 1.4kW, while the wider 07C911023F interchange market also contains listings with other output ratings and designs. An overlapping OE group does not prove that every version is physically or electrically interchangeable. Approve the replacement against the old-unit label, mounting, pinion data, terminal layout, engine application and cranking requirement, and keep different power versions on separate purchasing and inventory records.

Why must the 9-tooth clockwise pinion be confirmed?

Tooth count and rotation control how the pinion enters and drives the flywheel ring gear. A starter may bolt to the engine yet still use the wrong pinion geometry, engagement depth or rotation. That can cause grinding, incomplete engagement, broken teeth, a no-crank condition or costly ring-gear damage. Count the teeth, compare the drive-end appearance and confirm clockwise rotation using the same viewing convention before approving a sample or repeating a distributor order.

What should be tested before blaming the starter for slow cranking?

Check battery state of charge, battery condition and voltage under the actual start command, then measure voltage drop through the positive cable, grounds, terminals and control circuit. Look for corrosion, loose connections, heat damage, poor engine-to-chassis grounding and excessive engine mechanical load. A starter can turn slowly because available voltage and current are restricted upstream. Separate the electrical supply and engine condition from starter performance before authorizing replacement or opening a warranty claim.

What installation checks help prevent repeat failure?

Disconnect the battery according to the applicable service procedure and compare the new and removed starters before installation. Clean the mounting surface, cables and grounds, confirm terminal orientation and route the cables away from heat or moving parts. Do not use the mounting bolts to correct a flange mismatch. Tighten fasteners and electrical connections to the vehicle service specification, then verify smooth engagement, cranking and pinion release during controlled first starts before returning the vehicle to service.

How should a distributor inspect a bulk shipment of S0610S starters?

Link the purchase order, carton label and unit marking to the approved reference group and sealed sample. Sample-check 12V, 1.4kW and 9-tooth identity, mounting geometry, locating diameter, terminal orientation, housing condition, fastener security and packaging protection. Where suitable equipment is available, record the agreed no-load or functional test against the approved sample. Photograph and quarantine any mixed label, rating or configuration instead of blending questionable units into saleable inventory.

What information is needed for an accurate S0610S wholesale quotation?

Send every readable OE or aftermarket number, the Audi or Volkswagen model, production year, engine code and VIN or build information where available. Include clear photos of the old label, complete side, mounting face, drive end and rear terminals, plus required quantity, destination market, packaging or private-label request and any inspection documentation. Complete evidence allows the technical match and commercial review to proceed together, reducing repeated clarification and the cost of returns after shipment.

Request a Quote for S0610S Starter Motors

Send the complete OE or aftermarket reference, Audi or Volkswagen model, production date, engine code, old-unit photos, quantity, destination market and packaging or inspection needs for a fitment-focused B2B quotation.
