Automotive hydraulic valve service requiring a 13V 47W molded coil with matching Deutsch connector and bore
Confirm 13v, 47w, deutsch connector, coil bore and retaining method before installation.
| Quantity: | |
|---|---|
13V Automotive Hydraulic Solenoid Coil is a automotive hydraulic solenoid coil for Automotive hydraulic valve service requiring a 13V 47W molded coil with matching Deutsch connector and bore. Buyers should confirm old-coil evidence, 13v, deutsch connector, coil bore and body construction before approving replacement stock.
Specification | Confirmed Information |
|---|---|
Product Type | Automotive Hydraulic Solenoid Coil |
Primary Reference | Construction-specific replacement |
Cross References | No verified public OE number assigned |
Voltage | 13V |
Power | 47W |
Connector | Deutsch connector |
Insulation Class | N |
Application Scope | Automotive hydraulic valve service requiring a 13V 47W molded coil with matching Deutsch connector and bore |
MOQ | 50 pcs |
Delivery Time | 7 to 15 Days |
Warranty | 12 Months |
Complete every control point below before a sample or bulk order is released.
Approval Point | Buyer Review |
|---|---|
Reference | Use complete old-coil evidence |
Electrical | 13V; 47W; verify under load |
Connector | Deutsch connector |
Mechanical | Compare bore, height, body shape and retaining method |
Machine Evidence | Automotive hydraulic valve service requiring a 13V 47W molded coil with matching Deutsch connector and bore |
Separate electrical command, component movement and final machine response so the actual wiring or hydraulic fault is not hidden by parts replacement.
Observed Condition | Recommended Check |
|---|---|
No magnetic pull | Check loaded voltage, ground, continuity and coil resistance. |
Intermittent operation | Inspect terminal retention, lead damage and heat-related winding faults. |
Excessive heating | Confirm voltage, wattage, duty cycle and free valve-stem movement. |
Connector damage | Inspect keying, seals, corrosion and harness side loading. |
Correct coil, no hydraulic response | Inspect the armature, spool, oil cleanliness and machine command. |
When the approved sample and new lot are compared, keep the verified measurements and test result in the service record. Approve the complete old marking, 13v rating, 47w power reference, deutsch connector, coil bore, body height and retaining method. A matching voltage alone does not prove fit. Send straight-on connector, top-bore and side-profile photographs with measurements so the replacement is selected from electrical and mechanical evidence.
When a first article sample is approved, keep the verified measurements and test result in the service record. Measure voltage directly across the energized coil while the machine issues the real hydraulic command. An unloaded harness reading can hide resistance at a corroded terminal, relay or ground path. Compare the loaded result with 13v, record polarity where suppression is present and correct the circuit before blaming a new coil for weak magnetic pull.
When a repeat overheating case is investigated, keep the verified measurements and test result in the service record. Power affects current draw, heat generation and available magnetic force. A replacement with another wattage may fit the valve stem yet operate too weakly, run hotter or exceed a controller output. Confirm 47w from the old label or approved specification, then compare warm current and temperature during sample testing before releasing a bulk order.
When an installer measures unexpected voltage drop, keep the verified measurements and test result in the service record. Measure the internal bore diameter, overall height, outside width, shoulder position and retaining-nut clearance on the removed coil. Also record valve-stem length and connector orientation after installation. A coil can have the correct electrical rating but fail to seat fully or interfere with surrounding hardware when its mechanical envelope differs.
When a machine harness revision is compared, keep the verified measurements and test result in the service record. A plain winding may operate with either polarity, but a coil containing a diode or other suppression device can be polarity-sensitive. Reversed connection may prevent correct operation or damage the suppression component. Check markings and the equipment schematic before applying power, and keep pin assignments with the approved sample and production inspection record.
When a sample moves into volume production, keep the verified measurements and test result in the service record. Match the carton and coil labels to the purchase order, measure sample resistance, inspect connector keying and verify bore and height. Keep 12V, 24V and unusual voltage stock in separate labeled locations. A visual check alone is insufficient because several voltage versions can share the same molded body and connector.
When a mixed-voltage shipment reaches receiving inspection, keep the verified measurements and test result in the service record. Check terminal retention, harness movement, ground quality and voltage at the coil while the fault occurs. Heat can open a damaged winding, and vibration can interrupt a loose pin or broken lead. If electrical input remains stable, inspect the valve armature for contamination or sticking that changes as oil temperature and viscosity vary.
Send the complete old marking or component evidence, confirmed voltage, machine information, clear photos, measurements and required quantity for a fitment-focused B2B quotation.
