1811003191 Isuzu 6HK1 5.0kW Starter Motor Wholesale

1811003191 5.0kW Starter Motor Wholesale for Isuzu 6HK1

Public replacement data commonly associates 1811003191 with a 5.0kW Isuzu 6HK1 starter, which supports a clear purchasing identity for this product. Add the Hitachi machine model, engine plate and service deadline so the quotation reflects the buyer's actual equipment.

The supplier range also lists a 5.5kW product under the same reference group. This item must remain the 5.0kW line, with output visible beside eleven teeth, module 3, two Ø15 holes and the accepted terminal position.

1811003191 5.0kW Starter Motor Drawing for Excavator Buyers

The complete definition is 24V, 5.0kW, 11T, module 3 and clockwise rotation. Keeping 5.0kW in the item name and carton description prevents the 1811003191 reference from hiding the output difference when both versions enter one warehouse.

1811003191 Isuzu 6HK1 5.0kW Starter Drawing for Excavator Buyers — compare the drawing with the removed starter before placing a volume order.

Review two Ø15 holes, the 91 mm drive-end reference, the 45 mm and 63 mm axial values and the drive-nose area around Ø95. The 50° and 19° orientation is best preserved in a square front photograph of the removed starter.

1811003191 Starter Motor OE Matching for Hitachi Equipment

1811003191, 8980608540 and 8981412061 connect with M008T60971, M008T60973 and M8T61371. Add 5.0kW and the 6HK1X or Hitachi application to those numbers so offers do not drift toward the separate 5.5kW item.

Construction dealers can reserve units by supported excavator model, branch distance and typical breakdown demand. Attach the accepted 5.0kW nameplate and flange image to each stock entry, giving remote branches an immediate comparison before dispatch.

1811003191 5.0kW Starter Motor Branch Stock Support

Incoming checks should cover the 5.0kW label, eleven-tooth pinion, both mounting ears, terminal caps and sampled electrical performance. Keep the outer carton identity visible during put-away so the lower-output line cannot be mixed with the 5.5kW version.

Elecdura's video shows starter production and electrical testing for wholesale supply. Isuzu and Hitachi buyers can review capacity, inspection and packing while their 1811003191 order remains explicitly defined as the 5.0kW eleven-tooth product.

1811003191 5.0kW Starter Motor FAQs for Isuzu Buyers

How should an Isuzu buyer define the 1811003191 5.0kW version?

Define the item as “1811003191, 24V 5.0kW, 11T, module 3, CW” and attach photographs of the rating label, pinion, two-ear face and terminals. Add the Isuzu 6HK1X engine or Hitachi machine details. The 5.0kW value must remain visible because another product uses the same OE reference with a different output.

Why is 5.0kW a useful separation for this 6HK1 product?

The 5.0kW rating creates a clear purchasing and warehouse identity for this 1811003191 product. It separates the unit from the 5.5kW alternative while the OE number, tooth count and mounting style may look the same. Keep 5.0kW in the H1, quotation, purchase order, carton description and repeat-order history.

Which OE numbers broaden sourcing for the 5.0kW starter?

Useful cross references include 1811003240, 1811004140, 8980608540, M8T60971 and M9T60871, alongside the primary 1811003191 number. They broaden the supplier search but do not remove the need for a physical match. Buyers should keep the 5.0kW rating, 11T module-3 pinion and 6HK1X two-ear geometry attached to the reference group.

What measurements define the two-ear 6HK1X drive end?

Compare the two Ø15 mounting holes, 50° and 19° orientation references, Ø95 drive-nose area and 91 mm drive-end reference. The side view also shows 45 mm and 63 mm axial positions. Use square front and side photographs of the removed starter so the 6HK1X flange and pinion position can be checked consistently.

How should excavator branches prepare 5.0kW reserve stock?

Assign the 5.0kW product its own item code and bin, with 1811003191, 5.0kW and 11T visible on the label. Link branch quantities to confirmed Hitachi or Isuzu equipment records and keep the verified image set in the stock description. Replenish from actual usage while protecting a small reserve for machine-down demand.

Which nameplate and pinion photographs help receiving?

Photograph the full rating label straight on so 24V and 5.0kW are readable, then provide a close pinion view showing eleven teeth. Add front and side photographs that show the two-ear mounting face, drive position and terminals. Receiving should compare all views from the same sampled unit before adding it to 1811003191 stock.

What checks help separate starter faults from cable or battery faults?

Test the 24V battery bank under load, measure voltage drop on positive and ground cables, inspect terminals and grounds, and confirm the start-command signal before blaming the starter. Check ring-gear condition and engine resistance as well. Recording those results helps distributors distinguish a genuine 1811003191 starter fault from installation or vehicle electrical problems.

What should a 5.0kW 1811003191 quotation request contain?

Send the 6HK1X engine or Hitachi machine details, 1811003191 and other old-unit numbers, a readable 5.0kW label, eleven-tooth pinion photograph, mounting and terminal views, quantity, packing request and destination. State whether the order is for a sample, branch reserve or regular replenishment so Elecdura can prepare relevant wholesale terms.

Request 1811003191 5.0kW Starter Motor Wholesale Terms

Email the Isuzu 6HK1X engine or Hitachi machine details, complete 1811003191 and M8T markings, the 5.0kW label, flange, pinion and terminal photographs, quantity and destination to info@elecdurauto.com. Elecdura will compare this version and return wholesale pricing, lead time and shipping terms.
