36100-23060 / TM000A07901
36100-23060 / TM000A07901 / M52100 / D6RA79 / JS922 / 17708N / 1250302
Elecdura
Available for qualified orders
20 pcs
7 - 15 Days
Neutral packaging / private-label review
18 Months
36100-23060 / TM000A07901 / M52100 / D6RA79 / JS922 / 17708N / 1250302
Hyundai Avante and Coupe applications, including selected 1.8L and 2.0L G4GR or G4GC engines
Confirm Hyundai model, G4GR/G4GC engine and year, 12V 1.2kW rating, 8T 28 mm pinion, approximately 77 mm registration, mounting ears, plug and terminals.
| Quantity: | |
|---|---|
The controlled TM000A07901 / 36100-23060 ordering specification is 12V, 1.2kW, 8 teeth and clockwise rotation. Any 12-tooth or 1.4kW offer must remain a separate configuration until its complete OE, drive and mounting details are approved.
Hyundai application coverage spans several Avante and Coupe engines and years. Use the full 36100-23060 group and the vehicle's G4GR or G4GC record, not a generic Hyundai label, to control which starter enters distributor stock.
This video introduces Elecdura starter-motor production and supply capabilities. Use the verified 36100-23060 / TM000A07901 specification and fitment controls on this page for product approval.
Specification | Verified product and B2B ordering control |
Primary OE / reference | 36100-23060 |
OE / cross-reference group | 36100-23060 / TM000A07901 / M52100 / D6RA79 / JS922 / 17708N / 1250302 |
Application scope | Hyundai Avante and Coupe applications, including selected 1.8L and 2.0L G4GR or G4GC engines |
System voltage | 12V |
Rated power | 1.2kW |
Pinion teeth | 8T |
Rotation | CW / clockwise |
Drive detail | approximately 28 mm |
Order verification | Confirm Hyundai model, G4GR/G4GC engine and year, 12V 1.2kW rating, 8T 28 mm pinion, approximately 77 mm registration, mounting ears, plug and terminals. |
MOQ | 20 pcs, subject to final order confirmation |
Normal lead time | 7 - 15 days after order confirmation |
Warranty | 18 months under agreed sales terms |
The review group includes 36100-23060, TM000A07901, M52100, D6RA79, JS922, WAI 17708N and Valeo 1250302. Confirm the 8-tooth 28 mm drive, roughly 77 mm locating diameter, plug and mounting-ear layout before approving any substitute.
Approval point | Order verification for 36100-23060 |
Reference identity | 36100-23060 / TM000A07901 / M52100 / D6RA79 / JS922 / 17708N / 1250302 |
Application record | Hyundai Avante and Coupe applications, including selected 1.8L and 2.0L G4GR or G4GC engines |
Electrical version | 12V, 1.2kW, 8T, CW / clockwise |
Physical match | Confirm Hyundai model, G4GR/G4GC engine and year, 12V 1.2kW rating, 8T 28 mm pinion, approximately 77 mm registration, mounting ears, plug and terminals. |
Commercial release | Link the signed sample or dimensional record to the quotation, purchase order and receiving lot. |
Record the Hyundai model, engine displacement, G4GR or G4GC code, production month and removed starter label. Compare the two mounting ears, registration, pinion offset, plug keying and cable clearance. Avante and Coupe names cover enough versions that a model-only search can return the wrong starter.
Incoming samples should show 12V, 1.2kW and 8T, then match the 28 mm pinion, 77 mm registration, nose casting, plug and terminal layout in the approval file. Keep any 11T or 12T unit, different flange or 1.4kW label separate until the cross-reference is resolved.
Hyundai passenger and light-commercial distributors may use neutral or qualified private-label packaging with a clear 36100-23060 / TM000A07901 technical label. Protect the plug and pinion from impact and keep the lot identity visible for warranty tracking.
B2B item | Supply arrangement |
Quality position | Aftermarket replacement for verified OE/reference and fitment |
MOQ | 20 pcs |
Lead time | 7 - 15 days, subject to order confirmation |
Packaging | Neutral packaging or private-label review for qualified orders |
Receiving control | Incoming samples should show 12V, 1.2kW and 8T, then match the 28 mm pinion, 77 mm registration, nose casting, plug and terminal layout in the approval file. Keep any 11T or 12T unit, different flange or 1.4kW label separate until the cross-reference is resolved. |
Warranty | 18 months under agreed sales terms |
RFQ information | Complete references, application record, old-unit photos, quantity and destination for 36100-23060 |
The controlled 36100-23060 / TM000A07901 configuration is 12V, 1.2kW, 8 teeth and clockwise rotation. A unit marked 12 teeth or 1.4kW must not be substituted under the same approval. Buyers should compare the removed label, 28 mm pinion, 77 mm registration, plug and mounting dimensions before bulk release because nearby Hyundai starters can have similar housings.
This starter family is used with selected Hyundai Avante and Coupe models, including 1.8L and 2.0L G4GR or G4GC engines. The exact year and vehicle code still matter. Send the chassis and engine record with the old-unit label, because the same model name may span production changes or another starter family that is not interchangeable.
Count all eight teeth and measure the gear outside diameter near 28 mm, rest position and projected engagement depth. Compare the shaft, nose opening and ring-gear contact with the old unit. An 8-tooth count alone does not prove fitment if the offset or helix differs. Store the measurements and a drive-end photograph with the approved sample for repeat orders.
Check the locating diameter near 77 mm, two mounting-ear positions, threaded-hole details, nose depth and pinion base position. Compare the plug and B+ terminal clocking with the installed cable routing. A starter that looks correct from the side can still have a flange or terminal conflict. Measure before ordering rather than using mounting bolts to force alignment during installation.
They are useful catalog references within the same search group, but each supplied unit must still match the 12V, 1.2kW, 8-tooth drive, registration, mounting ears, plug and terminals. Supplier remanufacturing or supersession can introduce physical changes. Approve one sample and retain photographs or dimensions before replacing the primary 36100-23060 line in a distributor catalog.
Select samples from several cartons and verify the complete references, 12V and 1.2kW markings, 8-tooth 28 mm drive, 77 mm registration, mounting ears, plug, terminals and lot code. Compare against the signed sample and record deviations. An 11T or 12T drive, 1.4kW label or different plug should remain on hold rather than being mixed into sellable inventory.
Test battery state, ignition switch or relay output, start-signal voltage, cable drop and ground integrity under load. Inspect the ring gear and confirm that the engine rotates freely. Keep the readings with installation photos and the supplied label. Poor grounds, a weak battery or a damaged connector can imitate a failed TM000A07901 and should be excluded before a warranty return.
Private-label artwork may carry the distributor brand, but the technical label should retain 36100-23060 / TM000A07901, voltage, power, tooth count and lot identity. Use internal support that protects the plug, terminal studs and drive end. Agree barcode format and carton strength for the destination before production so receiving teams can scan and inspect the shipment without opening every box.
Send the Hyundai model, production year, G4GR or G4GC engine code, complete old-unit references and clear photographs of the mounting face, drive end, plug and terminals. Add quantity, destination, target delivery date, packaging and sample requirements. This gives the supplier enough information to quote the correct 1.2kW 8T starter rather than a generic Hyundai replacement.
Send the Hyundai model, engine code and year, complete label, mounting and plug photos, quantity and destination. Elecdura will review the verified 12V 1.2kW 8T configuration for quotation.
