ME012995 Mitsubishi Fuso 4D33 Starter Motor Wholesale

ME012995 Fuso 4D33 Starter Motor Wholesale for Canter Fleets

Canter parts suppliers often serve mixed FE-series fleets, so an ME012995 request is stronger when it identifies the 4D33 or 4D34 engine and the truck model. That pairing gives sales, purchasing and warehouse teams one clear description from the first quotation through later replenishment.

The M8T80071 family is widely recognized, yet visual similarity alone cannot establish the correct unit. Retain the nine-tooth pinion, module-3 drive, two Ø14.5 mounting holes and terminal side when comparing the removed starter with stock prepared for a Fuso customer.

ME012995 Starter Motor Specifications and Drawing for Buyers

ME012995 combines a 24V electrical platform with 3.2kW output, nine teeth, module 3 and clockwise rotation. Recording the full set prevents a same-engine enquiry from being fulfilled with a different drive-end or pinion version found elsewhere in the Canter range.

ME012995 Fuso 4D33 Starter Drawing for Wholesale Matching — compare the drawing with the removed starter before placing a volume order.

Use the drawing to compare both Ø14.5 holes, the R72 and R72.4 references, and the 18 mm and 21.7 mm axial dimensions. A square flange photograph makes the 20° and 14° orientation easier to judge before units enter branch inventory.

ME012995 Starter Motor OE Matching for Fuso Distributors

ME012995, ME014418, ME013008, ME017646 and M8T80071 are useful purchasing routes into this product family. Put the complete reference beside Fuso Canter FE507 and the engine code so cross-reference searches do not separate the part number from its intended commercial-vehicle use.

A distributor covering both 4D33 and 4D34 trucks can retain one confirmed product definition while recording customer demand by engine and chassis group. This keeps forecasting simple without allowing a broad Canter description to replace the nine-tooth drive and two-ear geometry.

ME012995 Starter Motor Stock Support for Commercial Importers

For the first shipment, receiving staff should sample the pinion count, both mounting ears, locating references, terminal protection and nameplate. Carton labels can carry ME012995, 24V 3.2kW and 9T so warehouse picking remains reliable when several Fuso starter families share the same shelf area.

Elecdura's video presents starter-motor assembly and electrical testing for wholesale programs. Fuso distributors can use it to discuss sampled test records, production capacity, neutral packing and planned delivery while the ME012995 order stays tied to the confirmed engine and mounting face.

ME012995 Starter Motor FAQs for Fuso Wholesale Buyers

Which Fuso details make an ME012995 enquiry complete?

State the Canter model, 4D33 or 4D34 engine code, chassis or fleet reference, every readable ME or M8T number and the required delivery date. Add front, pinion and cable-side photographs of the removed unit. Together, those details connect ME012995 to a defined truck and give purchasing a reusable basis for later replenishment.

How does M8T80071 relate to ME012995 sourcing?

M8T80071 is a strong cross-search number within the ME012995 family, alongside ME014418 and ME017646. After locating the group, retain 24V 3.2kW, nine teeth, module 3 and the two-ear flange. The Mitsubishi number narrows sourcing, while the engine and physical comparison determine whether the offered unit matches the Canter requirement.

Can one ME012995 stock line serve both 4D33 and 4D34 buyers?

One product line can serve confirmed 4D33 and 4D34 demand when the accepted starter configuration is the same. Record quantities by engine and truck model, then preserve the nine-tooth drive, two Ø14.5 holes and terminal side with each customer account. This keeps forecasting efficient without treating every Canter starter as interchangeable.

Which measurements should be compared on the two-ear flange?

Measure both Ø14.5 holes, compare the R72 and R72.4 drive-end references, and verify the 18 mm and 21.7 mm axial values. The two ears should be photographed squarely so the 20° and 14° orientation remains visible. These points distinguish the flange more reliably than a general side view of the starter body.

Why should a buyer record both 9T and module 3?

Nine teeth describes the pinion count, while module 3 describes the tooth size and gear form. Another 9T starter can therefore present a different flywheel interface. Carry both values with clockwise rotation and compare the removed gear from the side before the ME012995 unit moves into sample or wholesale inventory.

What old-starter photographs help a Canter parts distributor?

Take one square drive-end image, one direct pinion side view, both full body sides and a cable-side photograph showing the solenoid studs. Include the engine plate if the truck is available. This image set lets a distributor compare mounting orientation, gear form and terminal access without relying on an angled marketplace photograph.

How should ME012995 be labeled for branch inventory?

Use ME012995 as the main shelf identity, followed by Fuso 4D33/4D34, 24V 3.2kW and 9T module 3. Put the same description on the inner box and master carton. Keeping the accepted flange image in the warehouse item record helps staff separate it from nearby Canter starters during urgent picking.

What information supports firm ME012995 wholesale terms?

Provide the engine and truck details, complete references, clear flange, pinion and terminal photographs, order quantity, annual estimate, packing preference and destination. State whether the demand is a sample, normal stock or vehicle-down supply. Elecdura can then confirm the ME012995 version and return price, lead time, packing and freight options.

Request ME012995 Starter Motor Wholesale Pricing

Email the Fuso truck model, 4D33 or 4D34 engine details, every readable ME or M8T number, straight flange and terminal photographs, quantity, packing request and destination to info@elecdurauto.com. Elecdura will review the ME012995 configuration and return wholesale pricing, lead time and shipping options.
