6676957 Bobcat S175 S185 Starter Motor Wholesale

6676957 Starter Motor Wholesale Supply for Bobcat S175 and S185

S175 and S185 fleets often contain several model years and replacement histories. Quotations should include the machine serial and 6676957 identity so a superseding Bobcat number does not hide a different cable or mounting arrangement.

Bobcat replacement listings can show different output values for the wider 6676957 family. This product uses the supplier-defined 3.0kW version, so the rating label and photographed three-hole housing must accompany the reference.

6676957 Starter Motor Dimensions for Skid-Steer Fleet Buyers

The product combination is 12V, 3.0kW, 11T, module 3 and CW. Rental branches should display the output and tooth count on bin labels because the machine model alone may not describe earlier field replacements.

6676957 Bobcat S175 S185 Starter Dimensions for Fleet Buyers — compare the drawing with the removed starter before placing a volume order.

Check the Ø127 face, Ø88.5 locating section, three Ø11 holes, 46 mm drive position and 18 mm projection. Include the twin lower tubes and terminal orientation in the side image used for first-lot comparison.

6676957 Starter Motor References for Bobcat Parts Wholesalers

6676957 connects with Bobcat 6685190, Cargo 113727, WAI 18486N and STR54124. Keep the complete number found on the removed starter, the S175 or S185 serial and the accepted housing image on one order line.

A fleet can share verified stock across matching S175 and S185 machines, but serial ranges and installed cable updates should remain visible. An unfamiliar machine should be compared before the item enters a common rental pool.

6676957 Starter Motor Receiving and Rental-Branch Checks

Sample several first-lot cartons, count eleven teeth and inspect the three mounting ears, tubes and solenoid terminals. Reinforced body supports and pinion protection help prevent damage during repeated transfers between rental depots.

The Elecdura factory clip introduces starter production and electrical testing for wholesale supply. Bobcat parts buyers can pair it with serial-based screening, multi-carton sampling and depot replenishment planning for 6676957.

6676957 Starter Motor FAQs for Bobcat Fleet and Wholesale Buyers

Why is the Bobcat serial important for a 6676957 order?

S175 and S185 fleets can contain different model years and earlier field replacements. The serial helps parts teams connect the current machine to the removed starter and any cable update. For Bobcat S175 and S185 skid-steer loader applications, the RFQ should keep 6676957, 12V, 3.0kW, 11T, module 3 and CW on one purchasing line.

How should the 3.0kW version be identified?

Show 6676957 with 12V, 3.0kW, 11T and the accepted three-hole housing. A rating-label image helps distinguish this supplier-defined product from other outputs shown for the wider reference family. Before Bobcat S175 and S185 skid-steer loader applications stock is picked or received, warehouse staff should see the 3.0kW version and 6676957 identity together.

What should be measured on the Bobcat drive end?

Compare the Ø127 face, Ø88.5 locating section and three Ø11 holes. Check the 46 mm drive position and 18 mm projection against the removed S175 or S185 starter. A shared-stock decision is valid only for the supported bobcat s175 and s185 skid-steer loader applications shown by the retained records.

How should Bobcat 6685190 be handled in an enquiry?

Treat 6685190 as a related Bobcat number and retain the complete marking found on the old unit. The machine serial, cable layout and accepted product image should accompany the superseding reference. Those checks give receiving a repeatable physical baseline for the 6676957 product serving Bobcat S175 and S185 skid-steer loader applications.

Can S175 and S185 loaders use shared branch inventory?

They can share confirmed 6676957 stock after serial, housing and cable details match. Record consumption by model so an unfamiliar skid steer is checked before drawing from the common pool. For Bobcat S175 and S185 skid-steer loader applications, cross references widen sourcing while the accepted 6676957 application and product images guide selection.

Why should the twin lower tubes appear in photographs?

They make the represented housing easier to distinguish during remote comparison and receiving. A side image should show both tubes, the solenoid terminals and the relationship between the body and mounting face. The Bobcat S175 and S185 skid-steer loader applications shipping record should preserve the 6676957 label, destination allocation and inspected product version.

How can rental depots reduce freight damage?

Use reinforced supports beneath the heavy motor body and protect all three mounting ears. Cap the terminals, guard the pinion and avoid stacking pressure on the lower tubes. For Bobcat S175 and S185 skid-steer loader applications, diagnostic evidence protects the buyer and supplier from a return caused by the vehicle electrical system.

Which details produce a useful 6676957 quotation?

Provide model, serial, old-starter numbers, face, tube and terminal photographs and quantity. Add branch allocation, destination and required delivery date so pricing reflects the actual rental-fleet need. Elecdura can then review the exact 6676957 configuration for Bobcat S175 and S185 skid-steer loader applications and propose suitable supply terms.

Request 6676957 Bobcat S175 S185 Starter Motor Wholesale Pricing

Send the Bobcat model and serial, removed-starter numbers, clear face, tube and terminal photographs, quantity, branch split and destination to info@elecdurauto.com. Elecdura will assess the 6676957 version and quote wholesale supply.
