GT3576 800891-5001S Turbo Core for Volvo VM220

GT3576 800891-5001S Turbo Core Overview for Commercial Repair Buyers

GT3576 800891-5001S supports Volvo VM220 repair around the MWM 6.12 TCE 7.2L Euro 5 engine and 220 HP rating. Distributors should verify OE 7000467C1, turbo P/N 800891 or 709947-5028S, engine power, wastegate arrangement, and current nameplate before release. The VM330 uses a related but different GT3576S number family, so the shared MWM engine description cannot control stock selection. Power-specific records help regional fleets avoid wheel and housing mismatch.

GT3576 800891-5001S / 7000467C1 Turbo Core Specifications for Wholesale Buyers

800891-5001S / 7000467C1 Related Reference Numbers for Turbo Core Matching

GT3576 800891-5001S Matching Information for Distributor Sourcing

Volvo VM220 MWM 6.12 GT3576 Application Reference for Repair Programs

GT3576 800891-5001S CHRA Cartridge Value for Aftermarket Replacement Supply

GT3576 cartridge supply supports regional VM220 fleets when the fixed housings remain serviceable.

Power-rating separation protects warehouses from mixing 220 HP and 330 HP MWM turbo demand.

Wastegate and oil-system checks reduce repeat boost complaints after installation.

Elecdurauto supplies the core for confirmed VM220 repair programs.

GT3576 800891-5001S / 7000467C1 Turbo Core FAQ for Wholesale and Repair Buyers

Why must VM220 engine power be recorded for GT3576 800891?

MWM 6.12 TCE appears in several Volvo commercial ratings, including VM220 and VM330. The 220 HP rating supports the 800891 direction, while the higher-output product uses another Garrett family. Buyers should preserve the engine plate, turbo label, and OE 7000467C1 instead of ordering from displacement alone. Photographs and measurements also provide useful evidence if a later service claim requires review.

How should 709947-5028S be used with 800891-5001S?

The 709947 number is a related earlier Garrett reference that supports application research and service history. The buyer's actual nameplate should remain the primary order evidence. A distributor should record which number appeared on the confirmed VM220 unit and compare housings before treating both complete-turbo references as the same cartridge. Bulk release should remain pending whenever the current turbo and the application record do not agree.

What wastegate inspection belongs in a VM220 cartridge repair?

The pneumatic capsule should hold pressure, the rod and lever should move freely, and the flap should seat correctly. Incorrect preload, a leaking hose, or a worn shaft can create low or excessive boost after the core is fitted. The old control hardware must be tested separately from the rotating assembly. The workshop should document the result before the machine returns to high-load commercial operation.

Which regional-duty conditions can damage the GT3576 core?

Frequent payload changes, dusty roads, long idle periods, delayed oil service, and intake leakage can affect the VM220 turbo. Workshops should inspect filtration, oil pressure, charge-air cleanliness, crankcase ventilation, and exhaust restriction. Correct matching cannot protect the cartridge from debris or poor lubrication left after the earlier failure. Such controls help importers reduce wrong-version returns without overstating aftermarket fitment. Final release records should identify 800891-5001S, Volvo VM220 MWM 6.12, and the confirmed GT3576 configuration.

When is GT3576 housing reuse appropriate for 800891?

The housings should be free from cracks, deep contact marks, severe erosion, and distorted mounting faces. Wastegate hardware and locating features must match the confirmed 800891 assembly. If previous machining or mixed parts are present, measurements are required before choosing cartridge repair over a complete turbo. The evidence should remain linked to the purchase order, warehouse SKU, and repair report.

How should a Volvo distributor separate VM220 and VM330 stock?

The warehouse should use distinct turbo numbers, OE references, power ratings, photographs, and SKU labels. VM220 should remain connected with GT3576 800891, while VM330 uses GT3576S 796155. A common MWM 6.12 engine search may link both records, but it should never control picking. A number-led record gives repeat buyers a safer basis than a broad machine or engine description.
